Sony HBD-TZ215 - Back Panel Block Removal

HBD-TZ215/TZ715
11
2-7. BACK PANEL BLOCK
3
5 screw
(B3 u6)
4 wire (flat type) (9 core)
(CN400)
7 back panel block
1 power cord connector
(CN901)
CN901
LF901
POWER board
2 Remove the power cord
from the ditch.
Power cord
6 two screws
(BV3 (3-CR))
6 three screws
(BV3 (3-CR))
3RZHUFRUGVHWWLQJ
6 mm
cord bush (2104)power cord
190 + 5 mm
rear side
