60
HBD-TZ215/TZ715
SECTION 7
ELECTRICAL PARTS LIST
A-1843-033-A FL BOARD, COMPLETE
******************
< CAPACITOR >
C5000 1-100-909-11 CERAMIC CHIP 10uF 10% 6.3V
C5002 1-126-382-11 ELECT 100uF 20% 16V
C5003 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5004 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C5005 1-163-037-11 CERAMIC CHIP 0.022uF 10% 50V
C5006 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C5007 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C5008 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C5009 1-119-943-11 ELECT 47uF 20% 50V
C5010 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5011 1-126-157-11 ELECT 10uF 20% 16V
C5012 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5020 1-126-157-11 ELECT 10uF 20% 16V
C5021 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< CONNECTOR >
CN5000 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P
CN5005 1-779-548-21 CONNECTOR, FFC (LIF (NON-ZIF)) 11P
< DIODE >
D5000 6-500-848-01 DIODE MC2840-T112-1
D5001 6-500-848-01 DIODE MC2840-T112-1
D5002 6-503-014-01 DIODE DZ2J05100L
D5006 6-502-961-01 DIODE DA2J10100L
< IC >
IC5000 6-715-134-01 IC MM3404A33URE
IC5001 6-713-497-01 IC HT16515
IC5002
6-600-767-01 IC PNA4823M02S0
< JUMPER RESISTOR >
JR5000 1-216-295-91 SHORT CHIP 0
< COIL >
L5001 1-457-652-11 INDUCTOR 47uH
L5002 1-457-652-11 INDUCTOR 47uH
L5003 1-457-652-11 INDUCTOR 47uH
< FLUORESCENT INDICATOR TUBE >
ND5000 1-483-107-11 FLUORESCENT INDICATOR
< TRANSISTOR >
Q5000 6-552-713-01 TRANSISTOR QS5W2TR
< RESISTOR >
R5000 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R5001 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R5002 1-216-821-11 METAL CHIP 1K 5% 1/10W
R5003 1-216-813-11 METAL CHIP 220 5% 1/10W
R5004 1-216-813-11 METAL CHIP 220 5% 1/10W
R5005 1-216-813-11 METAL CHIP 220 5% 1/10W
R5006 1-216-839-11 METAL CHIP 33K 5% 1/10W
R5007 1-216-813-11 METAL CHIP 220 5% 1/10W
R5008 1-216-805-11 METAL CHIP 47 5% 1/10W
R5009 1-216-805-11 METAL CHIP 47 5% 1/10W
R5010 1-216-809-11 METAL CHIP 100 5% 1/10W
R5011 1-216-809-11 METAL CHIP 100 5% 1/10W
R5012 1-216-809-11 METAL CHIP 100 5% 1/10W
R5013 1-216-844-11 METAL CHIP 82K 5% 1/10W
R5014 1-216-809-11 METAL CHIP 100 5% 1/10W
R5018 1-216-805-11 METAL CHIP 47 5% 1/10W
R5083 1-216-813-11 METAL CHIP 220 5% 1/10W
R5084 1-216-813-11 METAL CHIP 220 5% 1/10W
< TRANSFORMER >
T5000 1-443-645-11 TRANSFORMER, DC CONVERTER
************************************************************
A-1746-218-A KEY-SW BOARD, COMPLETE
***********************
< CONNECTOR >
* CN5201 1-580-055-21 PIN, CONNECTOR (SMD) 2P
CN5202 1-580-057-11 PIN, CONNECTOR (SMD) 4P
< RESISTOR >
R5201 1-216-821-11 METAL CHIP 1K 5% 1/10W
R5202 1-216-809-11 METAL CHIP 100 5% 1/10W
R5203 1-216-821-11 METAL CHIP 1K 5% 1/10W
R5204 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
< SWITCH >
S5201 1-786-650-21 SWITCH, TACTILE (x)
S5202 1-786-650-21 SWITCH, TACTILE (N)
S5203 1-786-650-21 SWITCH, TACTILE (Z)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
KEY-SW
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• CAPACITORS
uF: μF
• COILS
uH: μH
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
• Abbreviation
E3 : Middle East & African models
E12 : Indian model
E32 : Latin American model
FL
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
The components identifi ed by mark 9 con-
tain confi dential information.
Strictly follow the instructions whenever the
components are repaired and/or replaced.
To Next Page
