HBD-TZ210/TZ230/TZ510/TZ630/TZ710
24
SECTION 5
DIAGRAMS
For Schematic Diagrams.
Note:
All capacitors are in PF unless otherwise noted. (p: pF) 50
WV or less are not indicated except for electrolytics and
tantalums.
All resistors are in : and 1/4 W or less unless otherwise
specifi ed.
f
: Internal component.
C : Panel designation.
THIS NOTE IS COMMON FOR PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS.
(In addition to this, the necessary note is printed in each block.)
A : B+ Line.
B : B– Line.
Voltages and waveforms are dc with respect to ground
under no-signal (detuned) conditions.
Voltages and waveforms are dc with respect to ground in
service mode.
Waveforms are taken with a oscilloscope.
Voltage variations may be noted due to normal production
tolerances.
no mark
: TUNER (FM)
< > : DVD PLAY
*
: Impossible to measure
Voltages are taken with VOM (Input impedance 10 M:).
Circled numbers refer to waveforms.
• Signal path.
F : TUNER
J : DVD PLAY
L : VIDEO
r : COMPONENT VIDEO
• Abbreviation
AR : Argentina model
AUS : Australian model
CH : Chinese model
CND : Canadian model
E3 : 240V AC area in E model
E12 : 220 – 240V AC area in E model
E32 : 110 – 240V AC area in E model
EA : Saudi Arabia model
HK : Hong Kong model
MX : Mexican model
PH : Philippines model
RU : Russian model
SAF : South African model
SP : Singapore model
TH : Thai model
TW : Taiwan model
For Printed Wiring Boards.
Note:
X : Parts extracted from the component side.
a
: Through hole.
: Pattern from the side which enables seeing.
(The other layers’ patterns are not indicated.)
Note:
The components identi-
ed by mark 0 or dotted
line with mark 0 are criti-
cal for safety.
Replace only with part
number specifi ed.
Note:
Les composants identifi és
par une marque 0 sont
critiques pour la sécurité.
Ne les remplacer que par
une pièce portant le nu-
méro spécifi é.
Caution:
Pattern face side:
(SIDE B)
Parts face side:
(SIDE A)
Parts on the pattern face side seen
from the pattern face are indicated.
Parts on the parts face side seen from
the parts face are indicated.
Indication of transistor.
C
B
These are omitted.
E
Q
CEB
These are omitted.
• Abbreviation
AR : Argentina model
AUS : Australian model
CH : Chinese model
CND : Canadian model
E3 : 240V AC area in E model
E12 : 220 – 240V AC area in E model
E32 : 110 – 240V AC area in E model
EA : Saudi Arabia model
HK : Hong Kong model
MX : Mexican model
PH : Philippines model
RU : Russian model
SAF : South African model
SP : Singapore model
TH : Thai model
TW : Taiwan model
Circuit Boards Location
SCART board (TZ230/TZ630)
MAIN board
POWER board
MS-203 board
KEY-SW board
FL board
USB KEY board
P-SW board
USB board
Ver. 1.1
