66
HBD-TZ210/TZ230/TZ510/TZ630/TZ710
SECTION 7
ELECTRICAL PARTS LIST
A-1746-214-A FL BOARD, COMPLETE
******************
< CAPACITOR >
C5000 1-100-909-11 CERAMIC CHIP 10uF 10% 6.3V
C5002 1-126-382-11 ELECT 100uF 20% 16V
C5003 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5004 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C5005 1-163-037-11 CERAMIC CHIP 0.022uF 10% 50V
C5006 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C5007 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C5008 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C5009 1-119-943-11 ELECT 47uF 20% 50V
C5010 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5011 1-126-157-11 ELECT 10uF 20% 16V
C5012 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5020 1-126-157-11 ELECT 10uF 20% 16V
C5021 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C5061 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN5000 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P
CN5005 1-779-548-21 CONNECTOR, FFC (LIF (NON-ZIF)) 11P
< DIODE >
D5000 6-500-848-01 DIODE MC2840-T112-1
D5001 6-500-848-01 DIODE MC2840-T112-1
D5002 6-501-729-01 DIODE MAZ8051GLLS0
D5006 6-501-817-01 DIODE MA2J1110GLS0
< IC >
IC5000 6-702-302-01 IC TK11133CSCL-G
IC5001 6-713-497-01 IC HT16515
IC5002 6-600-767-01 IC PNA4823M02S0 (IR)
< JUMPER RESISTOR >
JR5000 1-216-295-91 SHORT
CHIP 0
< COIL >
L5000 1-410-671-31 INDUCTOR 47uH
L5001 1-410-671-31 INDUCTOR 47uH
L5002 1-410-671-31 INDUCTOR 47uH
< FLUORESCENT INDICATOR TUBE >
ND5000 1-483-107-11 FLUORESCENT INDICATOR TUBE
< TRANSISTOR >
Q5000 6-550-065-01 TRANSISTOR CPH5504-TL-E
< RESISTOR >
R5000 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R5001 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R5002 1-216-821-11 METAL CHIP 1K 5% 1/10W
R5003 1-216-813-11 METAL CHIP 220 5% 1/10W
R5004 1-216-813-11 METAL CHIP 220 5% 1/10W
R5005 1-216-813-11 METAL CHIP 220 5% 1/10W
R5006 1-216-839-11 METAL CHIP 33K 5% 1/10W
R5007 1-216-813-11 METAL CHIP 220 5% 1/10W
R5008 1-216-805-11 METAL CHIP 47 5% 1/10W
R5009 1-216-805-11 METAL CHIP 47 5% 1/10W
R5010 1-216-809-11 METAL CHIP 100 5% 1/10W
R5011 1-216-809-11 METAL CHIP 100 5% 1/10W
R5012 1-216-809-11 METAL CHIP 100 5% 1/10W
R5013 1-216-844-11 METAL CHIP 82K 5% 1/10W
R5014 1-216-809-11 METAL CHIP 100 5% 1/10W
R5018 1-216-805-11 METAL CHIP 47 5% 1/10W
R5083 1-216-813-11 METAL CHIP 220 5% 1/10W
R5084 1-216-813-11 METAL CHIP 220 5% 1/10W
< TRANSFORMER >
T5000 1-443-645-11 TRANSFORMER, DC CONVERTER
************************************************************
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “
*
” are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• CAPACITORS
uF: µF
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . , uPA. . , µPA. . ,
uPB. . : µPB. . , uPC. . , µPC. . ,
uPD. . : µPD. .
FL
When indicating parts by reference num-
ber, please include the board name.
• Abbreviation
AR : Argentina model
AUS : Australian model
CH : Chinese model
CND : Canadian model
E3 : 240V AC area in E model
E12 : 220 – 240V AC area in E model
E32 : 110 – 240V AC area in E model
EA : Saudi Arabia model
HK : Hong Kong model
MX : Mexican model
PH : Philippines model
RU : Russian model
SAF : South African model
SP : Singapore model
TH : Thai model
TW : Taiwan model
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
Les composants identifi és par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce por-
tant le numéro spécifi é.
The components identifi ed by mark 9 con-
tain confi dential information.
Strictly follow the instructions whenever the
components are repaired and/or replaced.
Les composants identifi és par la marque
9 contiennent des informations confi den-
tielles.
Suivre scrupuleusement les instructions
chaque fois qu’un composant est remplacé
et / ou réparé.
Ver. 1.1
