— 96 —
• CAPACITORS
uF : µ F
• COILS
uH : µ H
• For detailed German, East European and CIS
model refer to AEP model.
• Abbreviation
CND : Canadian model
MX : Mexican model
SP : Singapore model
MY : Malaysia model
AUS : Australian model
• Due to standardization, replacements in the parts list
may be different from the parts specified in the
diagrams or the components used on the set.
• Items marked “*” are not stocked since they are
seldom required for routine service. Some delay
should be anticipated when ordering these items.
• RESISTORS
All resistors are in ohms
METAL: Metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F : nonflammable
• SEMICONDUCTORS
In each case, u: µ , for example:
uA...: µ A..., uPA...: µ PA..., uPB...: µ PB...,
uPC...: µ PC..., uPD...: µ PD...
Note:
When indicating parts by reference
number, please include the board
name.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
SECTION 7
ELECTRICAL PARTS LIST
* 1-667-267-11 AC SUPPLY BOARD (AEP,UK)
***************
* 1-666-445-11 AC SUPPLY BOARD (EXCEPT AEP,UK)
***************
< FUSE, FUSE HOLDER >
! F801 1-532-465-31 FUSE, TIME-LAG (T3.15AL/250V)
(E,SP,MY,MX,AUS)
! F801 1-576-107-12 FUSE (3.15A/250V) (US,CND)
! F801HA 1-533-213-31 HOLDER, FUSE
! F801HB 1-533-213-31 HOLDER, FUSE
< RESISTOR >
! R801 1-219-237-11 SOLID 3.3M 20% 1/2W
(US,CND)
**************************************************************
* A-4398-909-A CD DECODER BOARD, COMPLETE
**************************
< CAPACITOR >
C02 1-126-963-11 ELECT 4.7uF 20% 50V
C03 1-126-933-11 ELECT 100uF 20% 10V
C04 1-162-306-11 CERAMIC 0.01uF 20% 16V
C05 1-136-159-00 FILM 0.033uF 5% 50V
C06 1-162-306-11 CERAMIC 0.01uF 20% 16V
C07 1-136-159-00 FILM 0.033uF 5% 50V
C07A 1-162-199-31 CERAMIC 10PF 5% 50V
C08 1-161-494-00 CERAMIC 0.022uF 25V
C09 1-126-959-11 ELECT 0.47uF 20% 50V
C10 1-162-306-11 CERAMIC 0.01uF 20% 16V
C11 1-126-933-11 ELECT 100uF 20% 10V
C11A 1-164-159-11 CERAMIC 0.1uF 50V
C12 1-162-306-11 CERAMIC 0.01uF 20% 16V
C13 1-164-159-11 CERAMIC 0.1uF 50V
C14 1-162-302-11 CERAMIC 0.0022uF 30% 16V
C15 1-164-159-11 CERAMIC 0.1uF 50V
C16 1-136-159-00 FILM 0.033uF 5% 50V
C17 1-136-165-00 FILM 0.1uF 5% 50V
C18 1-164-159-11 CERAMIC 0.1uF 50V
C19 1-126-963-11 ELECT 4.7uF 20% 50V
C20 1-162-306-11 CERAMIC 0.01uF 20% 16V
C21 1-136-157-00 FILM 0.022uF 5% 50V
C22 1-126-933-11 ELECT 100uF 20% 10V
C23 1-164-159-11 CERAMIC 0.1uF 50V
C24 1-126-965-11 ELECT 22uF 20% 50V
C25 1-126-960-11 ELECT 1uF 20% 50V
C26 1-161-494-00 CERAMIC 0.022uF 30% 25V
C27 1-162-306-11 CERAMIC 0.01uF 20% 16V
C28 1-164-159-11 CERAMIC 0.1uF 50V
C29 1-126-935-11 ELECT 470uF 20% 16V
C30 1-126-933-11 ELECT 100uF 20% 10V
C31 1-162-600-11 CERAMIC 0.047uF 10% 16V
C32 1-162-301-11 CERAMIC 0.0015uF 30% 16V
C33 1-162-306-11 CERAMIC 0.01uF 20% 16V
C34 1-162-286-31 CERAMIC 220PF 10% 50V
C35 1-162-306-11 CERAMIC 0.01uF 20% 16V
C36 1-126-963-11 ELECT 4.7uF 20% 50V
C37 1-164-159-11 CERAMIC 0.1uF 50V
C38 1-102-958-00 CERAMIC 20PF 5% 50V
C39 1-102-958-00 CERAMIC 20PF 5% 50V
C42 1-126-012-11 ELECT 470uF 20% 16V
C43 1-126-933-11 ELECT 100uF 20% 10V
C45 1-126-923-11 ELECT 220uF 20% 10V
C46 1-126-933-11 ELECT 100uF 20% 10V
C51 1-162-288-31 CERAMIC 330PF 10% 50V
C51A 1-126-959-11 ELECT 0.47uF 20% 50V
C52 1-162-288-31 CERAMIC 330PF 10% 50V
C53 1-162-284-31 CERAMIC 150PF 10% 50V
C54 1-162-284-31 CERAMIC 150PF 10% 50V
C55 1-162-284-31 CERAMIC 150PF 10% 50V
C56 1-162-284-31 CERAMIC 150PF 10% 50V
C57 1-126-961-11 ELECT 2.2uF 20% 50V
C58 1-126-961-11 ELECT 2.2uF 20% 50V
C59 1-162-294-31 CERAMIC 0.001uF 10% 50V
C60 1-162-294-31 CERAMIC 0.001uF 10% 50V
C80 1-164-159-11 CERAMIC 0.1uF 50V
C81 1-164-159-11 CERAMIC 0.1uF 50V
C82 1-164-159-11 CERAMIC 0.1uF 50V
C83 1-164-159-11 CERAMIC 0.1uF 50V
C84 1-162-282-31 CERAMIC 100PF 10% 50V
C85 1-162-292-31 CERAMIC 680PF 10% 50V
C86 1-162-282-31 CERAMIC 100PF 10% 50V
C86A 1-161-494-00 CERAMIC 0.022uF 25V
C87 1-162-282-31 CERAMIC 100PF 10% 50V
C88 1-162-282-31 CERAMIC 100PF 10% 50V
C89 1-161-494-00 CERAMIC 0.022uF 25V
C90 1-161-494-00 CERAMIC 0.022uF 25V
C93 1-126-925-11 ELECT 470uF 20% 10V
C94 1-126-933-11 ELECT 100uF 20% 10V
C98 1-161-494-00 CERAMIC 0.022uF 25V
CD DECODER
AC SUPPLY
To Next Page
