— 5 —
SECTION 2
DISASSEMBL
Y
Note:
Follow the disassembly procedure in the numerical order given.
2-1. CD DOOR
2-2. CD MECHANISM DECK
CD door
1
T
wo screws (B3x8)
2
Screw
(BVTP3x10)
3
Screw
(BVTP3x10)
4
T
wo scre
ws
(BVTP3x10)
6
Flat type wire (21 core)
(CN09)
1
Pull out the CD tra
y and remove the
CD door with releasing cla
ws into the
direction of arrow
.
7
Harness
(Main board:CN08)
T
wo cra
ws
5
CD mechanism deck
4
6
