HCD-GPX33/GPX55/GPX77/GPX88
11
2-6. MB BOARD
2-7. CHASSIS SECTION
1 five screws
(+PWH 3 u 8 (SUMITITE))
3 two screws
(+PWH 3 u 8 (SUMITITE))
5 bracket, fan
6 fan, DC
7 chassis
2 REGULATOR, SWITCHING
4 two screws
(+BVTP 3 u 8)
4
1 CN101 (2P)
5 bushing (FBS001), cord
6 holder, wire
7 clamp, lead
2 five screws
(+BVTP 3 u 8)
qs two screws
(+BVTP 3 u 8)
3 one screw
(+BVTP 3 u 8)
8 panel, back
9 CN1001
(9P)
0 CN1000 (2P)
qa CN200 (6P)
qf thermal,
sheet
qg heat sink
(GSX8)
qd two screws
(+PTPWH 2.6 u L
(DIA8.0))
qd three screws
(+PTPWH 2.6 u L
(DIA8.0))
qf thermal, sheet
qg heat sink
(GSX3)
qh bracket,
heat sink
qh bracket,
heat sink
qj MB board
(GPX55/GPX77/GPX88)(GPX33)
(GPX55/GPX77/GPX88)(GPX33)
H
H
II
H
