HCD-GPX33/GPX55/GPX77/GPX88
SECTION 8
ELECTRICAL PARTS LIST
BASS BAZUCA BOARD
******************
< CONNECTOR >
* CN2002 1-750-005-11 PIN, CONNECTOR (PC BOARD) 4P
< DIODE >
D2000 6-503-944-51 DI SMLVN6RGB1U1 XQXB
D2001 6-503-944-51 DI SMLVN6RGB1U1 XQXB
< RESISTOR >
R2010 1-216-811-11 METAL CHIP 150 5% 1/10W
R2012 1-216-809-11 METAL CHIP 100 5% 1/10W
R2014 1-216-809-11 METAL CHIP 100 5% 1/10W
*************************************************************
DISPLAY BOARD
*************
< CAPACITOR >
C2201 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C2207 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C2214 1-112-723-21 CERAMIC CHIP 0.0047uF 10% 250V
C2215 1-118-373-11 CERAMIC CHIP 0.01uF 10% 50V
C2216 1-126-795-11 ELECT 10uF 20% 50V
C2223 1-118-373-11 CERAMIC CHIP 0.01uF 10% 50V
C2224 1-118-373-11 CERAMIC CHIP 0.01uF 10% 50V
C2228 1-118-373-11 CERAMIC CHIP 0.01uF 10% 50V
C2234 1-114-326-11 CAP, CERAMIC 0.22MF X7R 1608
C2235 1-114-326-11 CAP, CERAMIC 0.22MF X7R 1608
C2236 1-126-382-11 CAP, ELECT 100MF
C2237 2-126-382-11 CAP, ELECT 100MF
< CONNECTOR >
CN2200 1-568-830-11 CONNECTOR, FFC 11P
< DIODE >
D2201 6-503-775-01 DI CRH02 (T5R, SONY, XM)
D2202 6-503-775-01 DI CRH02 (T5R, SONY, XM)
D2203 6-503-775-01 DI CRH02 (T5R, SONY, XM)
D2204 6-503-775-01 DI CRH02 (T5R, SONY, XM)
D2207 6-502-970-01 DI DZ2J068M0L
< FLUORESCENT INDICATOR TUBE >
FL2200 1-483-465-11 VACUUM FLUORESCENT DISPLAY
< IC >
IC2200 6-600-768-01 IC PNA4823M03S0
< JUMPER RESISTOR >
JR2200 1-216-295-91
SHORT CHIP 0
JR2201 1-216-296-11 SHORT CHIP 0
JR2202 1-216-296-11 SHORT CHIP 0
JR2203 1-216-296-11 SHORT CHIP 0
JR2205 1-216-296-11 SHORT CHIP 0
JR2206 1-216-296-11 SHORT CHIP 0
JR2207 1-216-296-11 SHORT CHIP 0
JR2208 1-216-296-11 SHORT CHIP 0
JR2209 1-216-296-11 SHORT CHIP 0
< COIL >
L2200 1-412-541-21 INDUCTOR 220uH
< TRANSISTOR >
Q2200 6-553-083-01 TR PBSS4160T
Q2201 6-553-083-01 TR PBSS4160T
< RESISTOR >
R2200 1-216-801-11 METAL CHIP 22 5% 1/10W
R2201 1-216-797-11 METAL CHIP 10 5% 1/10W
R2202 1-216-809-11 METAL CHIP 100 5% 1/10W
R2203 1-216-809-11 METAL CHIP 100 5% 1/10W
R2204 1-216-809-11 METAL CHIP 100 5% 1/10W
R2205 1-216-809-11 METAL CHIP 100 5% 1/10W
R2206 1-216-797-11 METAL CHIP 10 5% 1/10W
R2207 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R2208 1-216-864-11 SHORT CHIP 0
R2210 1-216-839-11 METAL CHIP 33K 5% 1/10W
R2211 1-257-172-91 METAL CHIP 100 5% 1/3W
R2212 1-257-172-91 METAL CHIP 100 5% 1/3W
R2215 1-216-864-11 SHORT CHIP 0
< TRANSFORMER >
T2200 1-697-233-11 DC-DC CONVERTER TRANSFORMER
*************************************************************
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• CAPACITORS
uF: —F
• COILS
uH: —H
• SEMICONDUCTORS
In each case, u: —, for example:
uA. . : —A. . , uPA. . , —PA. . ,
uPB. . : —PB. . , uPC. . , —PC. . ,
uPD. . : —PD. .
• Abbreviation
AUS : Australian model
E2 : 120 V AC area in E model
E4 : African model
E51 : Chilean and Peruvian models
EA : Saudi Arabia model
MX : Mexican model
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
BASS BAZUCA
DISPLAY
