HCD-GTZ4/GTZ4i/GTZ5
SECTION 7
ELECTRICAL PARTS LIST
A-1660-819-A DISPLAY BOARD, COMPLETE (GTZ4i: US)
A-1660-822-A DISPLAY BOARD, COMPLETE (GTZ5)
A-1711-928-A DISPLAY BOARD, COMPLETE
(GTZ4/GTZ4i: AEP, AUS)
***********************
< CAPACITOR >
C1136 1-126-961-11 ELECT 2.2uF 20% 50V
C1137 1-126-961-11 ELECT 2.2uF 20% 50V
C1139 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1140 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C1147 1-126-965-91 ELECT 22uF 20% 50V
C1150 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C1151 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1152 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1153 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C1155 1-126-947-11 ELECT 47uF 20% 35V
C1156 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN1100 1-784-788-11 CONNECTOR, FFC 27P
CN1102 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P
CN1103 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P
< DIODE >
D1101 6-502-468-01 LED 1L034FV22D0DAC09 (I/
1
STANDBY)
D1102 6-501-752-01 DIODE MAZ8082GMLS0
D1104 8-719-060-27 LED SLR-325MCT31 (SUBWOOFER)
D1105 6-501-691-01 LED 1L434FV22D0TDF01 (STREAM)
(GTZ4/GTZ4i: AEP, AUS)
D1105 6-502-401-11 LED 1L434FA22E0TDT01 (STREAM) (GTZ4i: US)
D1105 6-502-513-01 LED 1L034PB12E0MTTZ1 (STREAM) (GTZ5)
D1106 6-501-691-01 LED 1L434FV22D0TDF01 (STREAM)
(GTZ4/GTZ4i: AEP, AUS)
D1106 6-502-401-11 LED 1L434FA22E0TDT01 (STREAM) (GTZ4i: US)
D1106 6-502-513-01 LED 1L034PB12E0MTTZ1 (STREAM) (GTZ5)
D1107 6-501-691-01 LED 1L434FV22D0TDF01 (STREAM)
(GTZ4/GTZ4i: AEP, AUS)
D1107 6-502-401-11 LED 1L434FA22E0TDT01 (STREAM) (GTZ4i: US)
D1107 6-502-513-01 LED 1L034PB12E0MTTZ1 (STREAM) (GTZ5)
D1108 6-501-691-01 LED 1L434FV22D0TDF01 (STREAM)
(GTZ4/GTZ4i: AEP, AUS)
D1108 6-502-401-11 LED 1L434FA22E0TDT01 (STREAM) (GTZ4i: US)
D1108 6-502-513-01 LED 1L034PB12E0MTTZ1 (STREAM) (GTZ5)
D1109 6-501-691-01 LED 1L434FV22D0TDF01 (STREAM)
(GTZ4/GTZ4i: AEP, AUS)
D1109 6-502-401-11 LED 1L434FA22E0TDT01 (STREAM) (GTZ4i: US)
D1109 6-502-513-01 LED 1L034PB12E0MTTZ1 (STREAM) (GTZ5)
D1110 6-501-691-01 LED 1L434FV22D0TDF01(STREAM)
(GTZ4/GTZ4i: AEP, AUS)
D1110 6-502-401-11 LED 1L434FA22E0TDT01 (STREAM) (GTZ4i: US)
D1110 6-502-513-01 LED 1L034PB12E0MTTZ1 (STREAM) (GTZ5)
< FLUORESCENT INDICATOR TUBE >
FL1100 1-483-077-11 VACUUM FLUORESCENT DISPLAYS
< IC >
IC1100 6-600-768-01 IC PNA4823M03S0
IC1101 6-713-680-01 IC PT6324-Q
< TRANSISTOR >
Q1114 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
Q1115 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
Q1116 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q1117 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q1118 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q1119 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q1120 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q1121 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q1122 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
< RESISTOR >
R1100 1-216-819-11 METAL CHIP 680 5% 1/10W
R1101 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1102 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1103 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1104 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1105 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R1106 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R1107 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R1108 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1109 1-216-835-11 METAL CHIP 15K 5% 1/10W
R1110 1-216-837-11 METAL CHIP 22K 5% 1/10W
R1112 1-216-839-11 METAL CHIP 33K 5% 1/10W
R1113 1-216-819-11 METAL CHIP 680 5% 1/10W
R1114 1-216-821-11 METAL CHIP 1K 5% 1/10W
R1115 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1116 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R1117 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R1118 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
R1119 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
DISPLAY
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• CAPACITORS
uF: μF
• COILS
uH: μH
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
• Abbreviation
AR : Argentine model
AUS : Australian model
E2 : 120V AC area in E model
E51 : Chilean and Peruvian models
MX : Mexican model
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
Ver. 1.1
