HCD-SPZ50/SPZ70
7
Note: Follow the disassembly procedure in the numerical order given.
3-2. CASE
• This set can be disassembled in the order shown below.
3-1. DISASSEMBLY FLOW
SECTION 3
DISASSEMBLY
3
3
1
three
screw
(B3)
2
two
screws
(case 3
TP2
)
2
two
screws
(case 3
TP2
)
4
case
SET
3-2. CASE
(Page 7)
3-8. TUNER (FM/AM)
(Page 10)
3-4. TAPE MECHANISM DECK (CFP42601)
(Page 8)
3-7. AMP/SP/POWER BOARD
(Page 10)
3-5. MAIN BOARD
(Page 9)
3-6. BASE UNIT (BU-K6BD83S-WOD ASSY)/
BELT (DLMA)
(Page 9)
3-3. FRONT PANEL ASSY
(Page 8)
