HCD-SPZ50/SPZ70
9
3-5. MAIN BOARD
3-6. BASE UNIT (BU-K6BD83S-WOD ASSY)/
BELT (DLM3A)
8
three
screws
(B3)
5
connector
(CN1203)
3
flexible flat cable (19 core)
(CN1302)
6
flexible flat cable (13 core)
(CN1308)
4
flexible flat cable (11 core) (AEP, UK)/
flexible flat cable (9 core) (EXCEPT AEP, UK
(CN1310)
2
connector
(CN1202)
1
connector
(CN1201)
9
MAIN board
7
flexible flat cable (23 core)
(CN1309)
7
four
screws
8
plate cam
9
Slide the tray.
1
four
screw
0
two belts
(DLM3A)
4
four coil springs
(insulator)
2
6
base unit
(BU-K6BD83S-WOD assy)
Note: Even if base unit is not removed,
two belts can remove.
3
four floating screws
(PTPWHM 2.6)
5
four
