DIAGNOSIS Menu
Menu items marked “1)” are displayed only on the HDCU5500/
3500.
Menu items marked “2)” are displayed only on the HDCU5000.
MULTICAST MULTICAST ADDRESS
ADDRESS 3
1)
AUDIO OUT LAN1
(N10) IP ADDRESS
PORT
AUDIO OUT LAN2
IP ADDRESS
PORT
HD TRUNK AUDIO OUT LAN1
IP ADDRESS
PORT
HD TRUNK AUDIO OUT LAN2
IP ADDRESS
PORT
PGM IN LAN1
IP ADDRESS
PORT
SRC IP
PGM IN LAN2
IP ADDRESS
PORT
SRC IP
MULTICAST MULTICAST ADDRESS
ADDRESS 4
1)
INTERCOM OUT LAN1
(N11) IP ADDRESS
PORT
INTERCOM OUT LAN2
IP ADDRESS
PORT
INTERCOM IN LAN1
IP ADDRESS
PORT
SRC IP
INTERCOM IN LAN2
IP ADDRESS
PORT
SRC IP
MULTICAST MULTICAST ADDRESS
ADDRESS 5
1)
META OUT LAN1-1
(N12) IP ADDRESS
PORT
META OUT LAN1-2
IP ADDRESS
PORT
META OUT LAN1-3
IP ADDRESS
PORT
META OUT LAN2-1
IP ADDRESS
PORT
META OUT LAN2-2
IP ADDRESS
PORT
META OUT LAN2-3
IP ADDRESS
PORT
EMBER+ EMBER+
(N13) PORT
PORT NUMBER
CONNECTION STAT U S
TSL UMD TSL UMD
(N14) PORT
PORT NUMBER
PACKET STAT US
SNMP SNMP
(N15) PORT
NAME
CONTACT
LOCATION
V1
ENABLE
V2C
ENABLE
V1/V2C
RO COMMUNITY
ALLOW HOST
HOST1 IP ADDRESS
HOST2 IP ADDRESS
HOST3 IP ADDRESS
SNMP TRAP SNMP TRAP
(N16) COMMUNITY
HOST1
IP ADDRESS
VERSION
HOST2
IP ADDRESS
VERSION
HOST3
IP ADDRESS
VERSION
SEND TEST TRAP
PING PORT
(N17) IP ADDRESS
PING
STAT I STICS
TRANSMITTED
PACKETS
RECEIVED PACKETS
PACKET LOSS
ROUND-TRIP MIN
ROUND-TRIP AVERAGE
ROUND-TRIP MAX
BOARD STATU S VIF
(D01) TX
NET
POWER ON HOUR METER
HOUR METER
SERIAL NUMBER MODEL NAME
(D02) SERIAL NUMBER
VERSION APPLICATION
(D03) OS
UPDATER
SY
VIF
TX1(HIGH)
TX1(ULTRA)
TX2
NET1
NET2
CAMERA DIAGNOSIS NAME
(D04) ROM VERSION
POWER UNIT STATUS CAM POWER SUPPLY
(D05) CABLE OPEN
CABLE SHORT
RCP POWER
FAN STAT U S PS FAN
1)
(D06) PS REAR FAN
FRONT FAN1/2
2)
FRONT FAN4
2)
REAR FAN
1)
REAR FAN1/2
2)
REAR FAN4
2)
