2-2
HDR-CX100/CX100E/CX105E/CX106E/CX120_L2
2-2-1. OVERALL SECTION
⋅ Cabinet (L)
⋅ Cabinet (Upper)
2-2-3.CABINET (R) SECTION
⋅ LCD Panel
⋅ OC-019 Board
⋅ HD-040 Board
2-2-5. MAIN BOARD SECTION
⋅ BT Panel
⋅ VC-559 Board
⋅ Lens Block
2-2-2. FRONT CABINET SECTION
⋅ Front Cabinet
⋅ Cabinet (R)
2-2-4.LCD PANEL SECTION
⋅ Hinge Block
⋅ PD-384 Board
⋅ LCD
- DISASSEMBLY FLOW -
Front Cabinet
LCD Panel
⋅ FP-1069 Flexible Board
⋅ PD-384 Board
Cabinet (R)
⋅ CK-214 Board
⋅ FP-1067 Flexible Board
⋅ HD-040 Board
⋅ OC-019 Board
BT Panel
⋅ JK-386 Board
⋅ FP-1068 Flexible Board
⋅ FP-1103 Flexible Board
⋅ MS-419 Board
Lens Block
⋅ CM-102 Board
⋅ FP-1070 Flexible Board
Cabinet (L)
VC-559 Board
⋅ FP-1066 Flexible Board
⋅ FP-1071 Flexible Board
LD-247 Board
Cabinet (Upper)
Speaker Holder
2-1. IDENTIFYING PARTS
