5-9
Ref. No. Part No. Description Ref. No. Part No. Description
5-2. ELECTRICAL PARTS LIST
HDR-CX100/CX100E/CX105E/CX106E/CX120_L2
A-1650-369-A CK-214 BOARD, COMPLETE
**********************
< CONNECTOR >
* CN5801 1-818-072-61 CONNECTOR, FFC/FPC (ZIF) 30P
* CN5802 1-816-655-51 FFC/CONNECTOR, FPC (LIF) 8P
CN5803 1-815-031-51 FFC/CONNECTOR, FPC (ZIF) 24P
CN5804 1-778-506-21 PIN, CONNECTOR (PC BOARD) 2P
< COMPOSITION CIRCUIT BLOCK >
RB5801 1-234-375-21 RES, NETWORK 1K (1005X4)
RB5802 1-234-376-11 RES, NETWORK 2.2K (1005X4)
A-1671-378-A CM-102 BOARD, COMPLETE
**********************
(IC6904 (CMOS imager) is not supplied, but this is included
in CM-102 complete board.)
< CAPACITOR >
C6906 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C6909 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C6910 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C6911 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
C6912 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C6913 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C6914 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
C6915 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C6916 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
C6917 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C6918 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C6919 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C6920 1-165-884-11 CERAMIC CHIP 2.2uF 10% 6.3V
C6921 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C6923 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C6924 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C6925 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C6926 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C6927 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C6928 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C6929 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C6930 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C6932 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C6933 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C6940 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C6941 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C6943 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
< CONNECTOR >
* CN6901 1-821-501-11 CONNECTOR, FPC (ZIF) 51P
< IC >
* IC6903 6-708-455-01 IC R1114Q271D-TR-FA
IC6904 (Not supplied) ASM030MR-CB-A (Note)
(IC6904 is supplied including in CM-102 complete board.)
< LINE FILTER >
* LF6901 1-457-648-21 COMMON MODE CHOKE COIL
* LF6902 1-457-648-21 COMMON MODE CHOKE COIL
* LF6903 1-457-648-21 COMMON MODE CHOKE COIL
* LF6904 1-457-648-21 COMMON MODE CHOKE COIL
* LF6905 1-457-648-21 COMMON MODE CHOKE COIL
< RESISTOR >
R6912 1-218-953-11 METAL CHIP 1K 5% 1/16W
R6916 1-218-941-81 METAL CHIP 100 5% 1/16W
R6918 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
A-1650-370-A HD-040 BOARD, COMPLETE
A-1650-370-A HD-040 BOARD, COMPLETE
**********************
< CONNECTOR >
* CN8501 1-820-586-61 CONNECTOR, FFC/FPC 28P
CN8502 1-821-724-21 CONNECTOR, SQUARE TYPE (USB) 5P
CN8503 1-821-166-21 HDMI CONNECTOR (HDMI OUT)
< LINE FILTER >
LF8505 1-457-223-11 COMMON MODE CHOKE COIL
< RESISTOR >
R8501 1-218-965-11 METAL CHIP 10K 5% 1/16W
A-1650-371-A JK-386 BOARD, COMPLETE
**********************
(BT7201 (lithium battery) is not included in JK-386 complete board.)
< BATTERY HOLDER >
0 BH7201 1-251-928-21 SOCKET, BATTERY
< BATTERY >
0 BT7201 1-756-134-12 BATTERY, STORAGE, LITHIUM
< CAPACITOR >
C6603 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C6604 1-137-987-81 CERAMIC CHIP 0.068uF 10% 10V
C6605 1-164-942-11 CERAMIC CHIP 0.0068uF 10% 16V
C6606 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C6607 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
Note: Be sure to read “Precautions for Replacement of
Imager” on page 4-2 when changing the imager.
Note: イメージャの交換時は4 - 3 ページのイメージャ交
換時の注意を必ずお読みください。
注意
電池の交換は，正しく行わないと破裂する恐れがあります。
電池を交換する場合には必ず同じ型名の電池又は同等品と交換
してください。
使用済み電池は，取扱指示に従って処分してください。
CAUTION
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
Dispose of used batteries according to the instructions.
• Refer to page 5-1 for mark 0.
CK-214 CM-102 HD-040 JK-386
Ver. 1.1 2009.02
The changed portions from
Ver. 1.0 are shown in blue.
