Sony ICF-SW7600GR - Portable Radio User Manual

1111
ICF-SW7600GR
4-3. PRINTED WIRING BOARD – MAIN BOARD (COMPONENT SIDE) –
15 16
A
B
C
D
E
F
G
H
I
17 18 19 20 21 22 23 24 25 26 27 28
MAIN BOARD (COMPONENT SIDE)
1-679-368-
11
(11)
B
TO
KEY BOARD
US
Note on Printed Wiring Boards:
• X : parts extracted from the component side.
•
a
: Through hole.
• : Pattern from the side which enables seeing.
(The other layers' patterns are not indicated.)
Caution:
Pattern face side: Parts on the pattern face side seen from
(Conductor Side) the pattern face are indicated.
Parts face side: Parts on the parts face side seen from
(Component Side) the parts face are indicated.

Sony ICF-SW7600GR - Portable Radio Specifications

General

Manufacturer	Sony
Model	ICF-SW7600GR
Display	LCD
Type	Portable Radio
Power Source	4 AA batteries or AC adapter
Features	SSB reception
Tuning Modes	Manual, Scan, Preset
Antenna	Telescopic antenna for FM/SW, built-in ferrite bar antenna for LW/MW
Speaker	Built-in
Headphone Jack	3.5 mm
Tuning Steps	FM: 0.05 MHz, SW: 1 kHz, MW: 9/10 kHz, LW: 9 kHz
Weight	617 g (1 lb 6 oz) including batteries
