Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
19
SECTION 6
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering these
items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
• Abbreviation
CH : Chinese model
CND : Canadian model
EA : Saudi Arabia model
JE : Tourist model
SP : Singapore model
When indicating parts by reference number,
please include the board name.
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
ICF-SW7600GR
KEY
* A-4440-289-A KEY BOARD, COMPLETE
********************
* 1-694-751-11 CONDUCTIVE BOARD, CONNECTION
* 3-227-389-01 HOLDER (LCD)
* 3-227-390-01 CASE (LCD)
< CAPACITOR >
C301 1-164-315-11 CERAMIC CHIP 470PF 5.00% 50V
C302 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C303 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C304 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C305 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C306 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C307 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C308 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C309 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C310 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C311 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C312 1-115-156-11 CERAMIC CHIP 1uF 10V
C313 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C314 1-115-156-11 CERAMIC CHIP 1uF 10V
C315 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C316 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C317 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C318 1-162-925-11 CERAMIC CHIP 68PF 5.00% 50V
C319 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C320 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C321 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C322 1-115-156-11 CERAMIC CHIP 1uF 10V
C323 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C324 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C325 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C326 1-115-416-11 CERAMIC CHIP 0.001uF 5.00% 25V
C327 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C328 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C329 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C330 1-164-315-11 CERAMIC CHIP 470PF 5.00% 50V
C331 1-136-177-00 FILM 1uF 5.00% 50V
C332 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C333 1-126-166-11 ELECT 2200uF 5.5V
C334 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C335 1-115-156-11 CERAMIC CHIP 1uF 10V
C336 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C338 1-115-156-11 CERAMIC CHIP 1uF 10V
C339 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C341 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C342 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C343 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
* CN301 1-691-077-21 HOUSING, CONNECTOR 18P
< DIODE >
D301 8-719-980-90 DIODE SLP-381F-51-AB
D302 8-719-988-61 DIODE 1SS355TE-17
D303 8-719-988-61 DIODE 1SS355TE-17
D304 8-719-988-61 DIODE 1SS355TE-17
D305 8-719-988-61 DIODE 1SS355TE-17
D306 8-719-941-04 DIODE SB007-03CP
D308 8-719-977-40 DIODE DTZ13B
< IC >
IC301 8-759-679-18 IC S-24C02BFJ-TB
IC302 6-800-111-01 IC uPD17073GB-564-1A7
IC303 8-759-549-49 IC S-80835ANNP-EDZ-T2
IC304 8-759-676-76 IC R3111Q311A-TR
IC305 8-759-492-58 IC RN5RL30AA-TL
< LIQUID CRYSTAL DISPLAY >
LCD1 1-804-194-11 DISPLAY PANEL, LIQUID CRYSTAL
< TRANSISTOR >
Q301 8-729-028-97 TRANSISTOR DTC114TUA-T106
Q302 8-729-220-93 TRANSISTOR 2SK209-G
Q303 8-729-220-93 TRANSISTOR 2SK209-G
Q304 8-729-423-52 TRANSISTOR 2SC3931-C
Q305 8-729-028-92 TRANSISTOR DTA144TUA-T106
Q306 8-729-402-32 TRANSISTOR 2SD1819A-R
< RESISTOR >
R301 1-216-797-11 METAL CHIP 10 5% 1/16W
R302 1-216-845-11 METAL CHIP 100K 5% 1/16W
R303 1-216-845-11 METAL CHIP 100K 5% 1/16W
R304 1-216-845-11 METAL CHIP 100K 5% 1/16W
To Next Page
