Sony ICF-SW7600GR User Manual

Listening to the radio26
GB
Receiving SSB and CW
transmissions
You can receive SSB (Single Side Band) and CW (Continuous Wave)
transmissions with this unit.
1 Press POWER ON/OFF to turn on the radio.
2 Press FM/AM to select AM.
3 Set the AM MODE selector to SSB.
4 Set the LSB/USB selector to either LSB or USB.
To receive CW transmission, select LSB.
5 Adjust the frequency.
For tuning, see Direct tuning (page 16), Manual tuning (page 18),
or Auto scan tuning (page 20).
6 Use SSB FINE TUNE control to fine tune in to a
frequency where you have the best reception.
You can fine tune the received frequency in a
range of about ±1.5 kHz. During this time, the
frequency display will not change.
Tip
For more information on SSB and CW, refer to “Tips on radio waves”,
page 41.
6
4
3
1
2

Sony ICF-SW7600GR Specifications

General

Radio type	Personal
Tuner type	Digital
FM band range	87.5 - 108 MHz
LW band range	150 - 285 kHz
PLL synthesizer	Yes
Supported radio bands	AM, FM, LW, SW
Preset stations quantity	100
Display type	LCD
Battery type	AA
Battery life (max)	12 h
Number of batteries supported	2
RMS rated power	- W
Subwoofer driver diameter (imperial)	3 \
Headphone outputs	1
MP3 playback	No
Product color	Gray
Apple docking compatibility	Not supported

Weight and Dimensions

Depth	35.3 mm
Width	118.8 mm
Height	90 mm
Weight	615 g
