Sony MHC-V02 Service Manual

MHC-V02
MHC-V02
2929
6-11. PRINTED WIRING BOARD - SPK LED Board -
• See page 24 for Circuit Boards Location.
•
: Uses unleaded solder.
6-10. PRINTED WIRING BOARD - VFD_IR Board -
• See page 24 for Circuit Boards Location.
•
: Uses unleaded solder.
1
A
B
C
D
E
F
2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
CL328
CL319
CL303
CL322
CL306
CL317
CL301
CL316
CL323
CL307
CL318
CL302
CL329
CL313
CL320
CL304
CL327
CL311
Q301
E
CL330
CL314
CL309
CL324
CL308
CL315
CL310
CL321
CL305
C301
C302
C304
C305
C306
C307
C308 C309
C310
D301
K
A
R301
R302
R303 R304
R305
R306
R313
R310
R311
R312
C303
ND301
VACUUM FLUORESCENT
DISPLAY
IC301
1
2
CN302
C311
C312
C313
C314
JW3001
1
2
11
10
CN301
JW3008
VFD_IR BOARD
1-983-977-
11
(11)
MOTHERBOARD
BOARD
CN1003
(Page 25)
>002P
SPK LED BOARD
NO400
(Page 29)
>004P
1
A
B
C
D
E
2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
CL401
CL402
D401
12
NO400
VFD_IR BOARD
CN302
(Page 29)
>004P
1-983-978-
11
(11)
SPK LED BOARD
SYSSET
2019/02/2822:48:45(GMT+09:00)

Sony MHC-V02 Specifications

General

Speaker type	-
Speaker placement	Floor
Built-in amplifier	Yes
Number of woofer drivers	1
Number of tweeter drivers	2
Type	Home audio mini system
Control type	Buttons, Wireless
Display type	LED
Cassette deck	No
Product color	Black
Housing material	Plastic
Disc loading type	Top
Number of optical discs	1 discs
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Quantity per pack	1 pc(s)
RMS rated power	- W
Power source	AC
Power source type	AC, Battery
Power consumption (standby)	0.5 W
Power consumption (typical)	25 W
Bluetooth version	4.2
Coloration	Monochromatic
Bluetooth profiles	A2DP, AVRCP, SPP
Illumination location	Front
Analog signal format system	NTSC, PAL
Compatible operating systems	Android, iOS
Supported radio bands	Not supported
Recording on	USB
Disc types supported	CD, CD-R, CD-RW
Playback disc formats	CD audio
Audio formats supported	AAC, MP3, WAV, WMA
Volume control	Digital

Weight and Dimensions

Depth	306 mm
Width	281 mm
Height	500 mm
Weight	6000 g
Woofer diameter	180 mm
Tweeter diameter	40 mm
