6-15
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
C103 1-119-923-81 CERAMIC CHIP 0.047uF 10% 10V
C104 1-164-942-11 CERAMIC CHIP 0.0068uF 10% 16V
C105 1-164-173-11 CERAMIC CHIP 0.0039uF 10% 50V
C106 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C107 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C108 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C109 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C110 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C111 1-119-923-81 CERAMIC CHIP 0.047uF 10% 10V
C113 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C114 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C115 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C116 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C117 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C118 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C121 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C125 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C130 1-164-941-11 CERAMIC CHIP 0.0047uF 10% 16V
C134 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C140 1-104-852-11 TANTAL. CHIP 22uF 20% 10V
C141 1-104-852-11 TANTAL. CHIP 22uF 20% 10V
C142 1-135-208-11 TANTAL. CHIP 1uF 20% 10V
C143 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C144 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C146 1-104-852-11 TANTAL. CHIP 22uF 20% 10V
C147 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C201 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C203 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C204 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C205 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C206 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C207 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C208 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C209 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C210 1-164-882-11 CERAMIC CHIP 220PF 5% 16V
C213 1-164-882-11 CERAMIC CHIP 220PF 5% 16V
C214 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C215 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C216 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C218 1-164-874-11 CERAMIC CHIP 100PF 5% 16V
C220 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C222 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C223 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C224 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C225 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C229 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C234 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C236 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C245 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C246 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C247 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C248 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C251 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C252 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C254 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C255 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C257 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C258 1-110-569-11 TANTAL. CHIP 47uF 20% 6.3V
C259 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C260 1-119-750-11 TANTAL. CHIP 22uF 20% 6.3V
C262 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C263 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C265 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C266 1-164-858-11 CERAMIC CHIP 22PF 5% 16V
C400 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C401 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C403 1-117-920-11 TANTAL. CHIP 10uF 20% 6.3V
C404 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C405 1-164-937-11 CERAMIC CHIP 0.001uF 10% 16V
C406 1-164-937-11 CERAMIC CHIP 0.001uF 10% 16V
C408 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C409 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C410 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C411 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C412 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C414 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C416 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C417 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C421 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C422 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C423 1-164-850-11 CERAMIC CHIP 10PF 0.50PF 16V
C424 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C426 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C427 1-164-937-11 CERAMIC CHIP 0.001uF 10% 16V
C428 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C430 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C433 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C436 1-110-569-11 TANTAL. CHIP 47uF 20% 6.3V
C437 1-107-686-11 TANTAL. CHIP 4.7uF 20% 16V
C438 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C439 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C440 1-104-852-11 TANTAL. CHIP 22uF 20% 10V
C442 1-164-850-11 CERAMIC CHIP 10PF 0.50PF 16V
C443 1-164-850-11 CERAMIC CHIP 10PF 0.50PF 16V
C444 1-119-750-11 TANTAL. CHIP 22uF 20% 6.3V
C445 1-117-920-11 TANTAL. CHIP 10uF 20% 6.3V
C446 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C449 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C452 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C453 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C454 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C461 1-164-880-11 CERAMIC CHIP 180PF 5% 16V
C462 1-119-923-81 CERAMIC CHIP 0.047uF 10% 10V
C463 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C464 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C465 1-164-937-11 CERAMIC CHIP 0.001uF 10% 16V
C466 1-164-882-11 CERAMIC CHIP 220PF 5% 16V
C468 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C469 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C470 1-164-860-11 CERAMIC CHIP 27PF 5% 16V
C471 1-119-923-81 CERAMIC CHIP 0.047uF 10% 10V
C472 1-119-923-81 CERAMIC CHIP 0.047uF 10% 10V
C473 1-119-923-81 CERAMIC CHIP 0.047uF 10% 10V
< CONNECTOR >
CN001 1-770-107-21 CONNECTOR, FFC/FPC (ZIF) 32P
CN002 1-573-927-11 CONNECTOR, FFC/FPC 18P
* CN404 1-766-883-31 CONNECTOR, BOARD TO BOARD 50P
CN405 1-784-342-21 HOUSING, CONNECTOR 2P
MD-083
