19
Configuring the Network
Preparation
Configuring the Network
When power is turned on, all devices connected to the
MVS system LAN are detected and corresponding settings
are registered.
1
Display the menu.
a Open the Engineering Setup >System >Network
Config menu (7311).
2
Set the group ID.
Network Config menu
a Check the group ID.
In this example, check that the group ID is set to
“1”.
If the group ID is not set to “1”, press [Group ID]
and change the setting.
For details about settings, refer to the User’s
Guide.
3
The connected devices are automatically detected.
a Press [Auto Config].
b Check the message, then press [Yes].
A list of detected devices appears.
4
Register the list of detected devices.
a Press [Define].
b Check the message, then press [Yes].
The list is registered as the network settings when
power is turned on.
Group ID
Auto Config Define
DME
Control panel
Switcher processor
To Next Page
