Sony MVS-6500 System User Manual

28
Setting Tally
Preparation
c Set the tally type.
In this example, select [Group1-4] in the <Tally
Group> group, and [R1] and [G1] in the <Tally
Type> group, turning them on.
Turn off [R2] to [R4] and [G2] to [G4] in [Group1-
4], and [R5] to [R8] and [G5] to [G8] in [Group 5-
8].
d Press [Source Assign].
The Source Assign menu (7367.1) appears.
e In the <Serial Tally Port> group, select the target
port.
In this example, select [Panel Port].
f Press [All Clear].
g Check the message, then press [Yes].
The source addresses assigned to each of the serial
tally bits are set to the default.
If you use other than the default values for serial
tally bits, change the source address settings.
For details about settings, refer to the User’s
Guide.
To output parallel tallies from a DCU, display the
Engineering Setup >Router/Tally >Parallel Tally
menu (7366) in step 3 and make settings.
For details about settings, refer to the User’s Guide.
Input/outputs for MVS-6500 system
assigned to S-Bus matrix
Matrix size: 136 x 138
•Source
Memo
No. Source
1Primary 1
2Primary 2
3Primary 3
4Primary 4
5Primary 5
6Primary 6
7Primary 7
8Primary 8
9Primary 9
10 Primary 10
11 Primary 11
12 Primary 12
13 Primary 13
14 Primary 14
15 Primary 15
16 Primary 16
17 Primary 17
18 Primary 18
19 Primary 19
20 Primary 20
21 Primary 21
22 Primary 22
23 Primary 23
24 Primary 24
25 Primary 25
26 Primary 26
27 Primary 27
28 Primary 28
29 Primary 29
30 Primary 30
31 Primary 31
32 Primary 32
33 Primary 33
34 Primary 34
35 Primary 35
36 Primary 36
37 Primary 37
38 Primary 38
39 Primary 39
40 Primary 40
41 Primary 41
42 Primary 42
43 Primary 43
44 Primary 44
45 Primary 45
46 Primary 46
47 Primary 47
48 Primary 48
49
50
51
52
53
54
55
56
57
58
59
60
61
No. Source
