Preparing the camera
Identifying parts
See the pages in parentheses for details of operation.
When the lens is removed
A Flash
B ON/OFF (Power) switch (23)
C Shutter button (26)
D AF illuminator/Self-timer lamp/
Smile Shutter lamp
E Lens release button (20)
F Image sensor position mark
G Smart Accessory Terminal 2
1)
H Microphone
2)
I Lens (19)
J Mount
K Image sensor
3)
L Lens contacts
3)
1)
Accessories for the Smart
Accessory Terminal can be also
attached.
2)
Do not cover this part during movie
recording.
3)
Do not touch this part directly.
