Sony NSX-24GT1 User Manual

Top Page > Keypad/Parts & Controls > Keys and Buttons
Keys and Buttons
Device control area
Video control area
Keyboard area
Side area
Device control area
/ / / (4-directions)/ENTER
Press
/ / / to select an item. Then press ENTER to confirm the highlighted item.
(1)
VOL +/− (VOLUME)
Adjusts the volume.
(2)
(ON/STANDBY) (BD/EXT)
Turns on the connected device or sets to standby mode.
(3)
AMP
Allows you to control the connected AV Receiver.
Keys with orange dots are active when the AMP indicator is on.
See Preparing to Control an AV Receiver.
(4)
(ON/STANDBY) (TV)
Turns on the TV.
(5)
INPUT
Switches inputs of connected devices.
(6)
CH +/−
Selects the next (+) or previous (−) channel. See Watching Live TV.
When CH is pressed with Fn, the page moves up or down.
(7)
(BACK)
Returns to the previous display or shuts down the application or the task.
(BACK) functions regardless of displayed content.
(8)
(HOME)
Displays the Home menu.
The Home menu is a gateway to various content. See Using the Home menu.
(9)
(WINDOW)
Switches the window style.
When (WINDOW) is pressed, PIP (Picture-in-Picture) is activated. PIP (Picture-in-Picture)
(10)
Did You Know
Home
Keypad
Keys and Buttons
Re-pairing
Search
Using Applications
Internet
TV
Playback
Connection
Settings
Parts & Controls
Troubleshooting / FAQ
Others
Media Remote
Search Help Guide
FAQ
NSX-24GT1/NSX-32GT1/NSX-40GT1/NSX-46GT1
19

Sony NSX-24GT1 Specifications

Display Specs

aspect ratio	16:9
display resolution	1920 x 1080p
screen size	24 inches

Power

power requirements (voltage)	AC 120V
power requirements (frequency)	60Hz
power consumption (in operation)	84 W

Inputs and Outputs

hdmi connections input(s)	4 (2 Rear/ 2 Side)
usb 2.0	4 (Side)
ethernet connection(s)	10BASE-T/100BASE-TX/1000BASE-T (Rear)

Weight and Dimensions

dimensions without pedestal	571 x 353 x 71 mm
dimensions with pedestal	571 x 381 x 190 mm
weight without pedestal	8.7 kg
weight with pedestal	10.1 kg
