HD SDI Connector Input/Output Specifications
Appendix
the BPU-4000 to the HD SDI-1 to HD-SDI-4 connectors
of port B of the unit.
For output ports
Out: Represents all SDI IN/OUT 1 to 8 connector outputs.
For single system signal formats transferred using
more than one SDI cable, it is represented by Out1-1,
Out1-2, and so on. 8-system output is supported for
formats that are transferred using one SDI cable
(Single Link), 4-system output for formats using two
cables (Dual Link), and 2-system output for formats
using four cables (Quad Link).
DC: Down-converted 4K to HD signal output for monitor.
Char: Superimposed character information output for
monitor.
–: Not used.
a) When [Output Port SDI-1,2,3,4] is set to [Off] on the [Setup] tab of the
[System] screen in the web menu, no signal is output.
b) The format of the signals output from the HD SDI IN/OUT 9 and 10
connectors is set when the video format is specified on the [Board] tab of
the [System] screen of the web menu. The supported formats for the HD
SDI IN/OUT 9 and 10 connectors vary depending on the signal format
specified for the HD SDI IN/OUT 1 to 8 connectors.
Format SDI HD SDI IN/OUT connector
1
a)
2
a)
3
a)
4
a)
5 6 7 8
9
b)
10
b)
4K 422 23p/Psf to
29p/Psf
1.5G Out1-1 Out1-2 Out1-3 Out1-4 Out1-1 Out1-2 Out1-3 Out1-4 DC/Char DC/Char
3G Out1-1 Out1-2 Out1-1 Out1-2 Out1-1 Out1-2 Out1-1 Out1-2 DC/Char DC/Char
50p/59p 3G Out1-1 Out1-2 Out1-3 Out1-4 Out1-1 Out1-2 Out1-3 Out1-4 DC/Char DC/Char
HD 422 50i/59i 1.5G Out Out Out Out Out Out Out Out Char Char
23p/Psf to
29p/Psf
1.5G Out Out Out Out Out Out Out Out Char Char
50p/59p 1.5G Out1-1 Out1-2 Out1-1 Out1-2 Out1-1 Out1-2 Out1-1 Out1-2 Char Char
3G Out Out Out Out Out Out Out Out Char Char
