Sony STR-DH710 Service Manual

STR-DH710
6
1-2. BACK PANEL SECTION
1-3. FRONT PANEL SECTION
%
$
$
%
 CNP901 (2P)
 wire (flat type)
(19 core)
(CN3512)
 CN3510 (5P)
 seven screws
(+BVTP 3 × 8)
 nine screws
(+BVTP 3 × 8)
 four screws
(+BVTP 3 × 8)
 four screws
(+BVTP 3 × 8)
 five screws
(+BVTP 3 × 8)
 wire (flat type)
(9 core)
(CN2003)
 CNP792 (4P)
 wire (flat type)
(27 core) (CN2020)
 Clip
 five screws
(+BVTP 3 × 8)
 front panel section
 saranet
cushion
