64
STR-DH710
SECTION 6
ELECTRICAL PARTS LIST
CONNECTION BOARD
***************************
< CONNECTOR >
CNP195 1-778-226-21 CONNECTOR, BOARD TO BOARD 6P
CNS195 1-778-227-41 CONNECTOR, BOARD TO BOARD 6P
***********************************************************************************************
A-1747-566-A DIGITAL BOARD, COMPLETE
***********************************
3-087-053-01 +BVTP2.6 (3CR)
< CAPACITOR >
C2000 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2002 1-112-300-91 CERAMIC CHIP 4.7uF 10% 10V
C2003 1-112-300-91 CERAMIC CHIP 4.7uF 10% 10V
C2004 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C2005 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2006 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2007 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2008 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2010 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2012 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2013 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2015 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2016 1-112-300-91 CERAMIC CHIP 4.7uF 10% 10V
C2017 1-135-372-31 ELECT 470uF 20% 10V
C2018 1-137-980-91 CERAMIC CHIP 0.47uF 10% 50V
C2019 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2020 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2021 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2023 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C2024 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2025 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2026 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2027 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2030 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C2031 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C2032 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2033 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2034 1-137-980-91 CERAMIC CHIP 0.47uF 10% 50V
C2035 1-126-947-11 ELECT 47uF 20% 35V
C2044 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2045 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2047 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2048 1-126-947-11 ELECT 47uF 20% 35V
C2049 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C2050 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2051 1-126-947-11 ELECT 47uF 20% 35V
C2052 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2054 1-126-925-91 ELECT 470uF 20% 10V
C2055 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2056 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2057 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2058 1-164-847-11 CERAMIC CHIP 7PF 0.5PF 50V
C2059 1-164-847-11 CERAMIC CHIP 7PF 0.5PF 50V
C2060 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2061 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2062 1-126-925-91 ELECT 470uF 20% 10V
C2063 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2064 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2065 1-126-933-11 ELECT 100uF 20% 16V
C2066 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C2067 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2068 1-128-590-11 ELECT CHIP 100uF 20% 6.3V
C2069 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C2070 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2071 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2072 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2073 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2074 1-126-925-91 ELECT 470uF 20% 10V
C2075 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C2076 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2077 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2079 1-126-933-11 ELECT 100uF 20% 16V
C2080 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2081 1-126-933-11 ELECT 100uF 20% 16V
C2082 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C2083 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2084 1-126-947-11 ELECT 47uF 20% 35V
C2085 1-126-965-91 ELECT 22uF 20% 50V
C2086 1-126-933-11 ELECT 100uF 20% 16V
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
CONNECTION
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• Items marked “
*
” are not stocked since
they are seldom required for routine ser-
vice.
Some delay should be anticipated when
ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• CAPACITORS
uF: μF
• COILS
uH: μH
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
• Abbreviation
CND : Canadian model
The components identified by mark
0
or dotted line with mark
0
are critical for
safety.
Replace only with part number specifi ed.
Les composants identifi és par une marque
0
sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifi é.
The components identifi ed by mark
9
con-
tain confi dential information.
Strictly follow the instructions whenever
the components are repaired and/or re-
placed.
Les composants identifi és par la marque
9
contiennent des informations confi denti-
elles.
Suivre scrupuleusement les instructions
chaque fois qu’un composant est rem-
placé et / ou réparé.
DIGITAL
