Rear panel
68
143
576
2
LR
VIDEO
OUT
MONITOR
L
R
DIGITAL
(ASSIGNABLE)
DC5V
0.7A MAX
HDMI
ANTENNA
DMPORT
IN 4
ASSIGNABLE (INPUT ONLY)
IN 3
IN 2
IN 3
IN 1
OUT
AM
Y
P
B /
C B
COMPONENT VIDEO
OUT
IN
P R /
C R
IN 2
IN 1
MONITOR
OUT
SA-CD/CD/CD-R VIDEO 1
IN
TV
AUDIO
IN
VIDEO
IN
SAT
AUDIO
OUT
AUDIO
OUT
VIDEO
OUT
OPTICAL IN
AUDIO
IN
VIDEO
IN
SUBWOOFER
AUDIO
IN
VIDEO
IN
BD
LR
L
R
SPEAKERS
SAT IN BD IN
DVD IN
OPTICAL
CENTER
FRONT A
COAXIAL
ASSIGNABLE (INPUT ONLY)
SURROUND BACK/
FRONT B/
BI-AMP
TV
SIRIUS
LR
SURROUND
(for AUDIO)
EZW-T100
A S-AIR (EZW-T100)
CAUTION
Please do not remove
the slot cover until
you want to install
the wireless
transmitter.
Connects to a
wireless transmitter
(not supplied) (page
99).
B DMPORT
DMPORT
jack
Connects to a Sony
DIGITAL MEDIA
PORT adapter
(page 23).
With slot cover
slot
C ANTENNA section
FM
ANTENNA
jack
Connects to the FM
wire antenna (aerial)
supplied with this
receiver (page 35).
AM
ANTENNA
terminals
Connects to the AM
loop antenna (aerial)
supplied with this
receiver (page 35).
SIRIUS jack Connects to a
SiriusConnect Home
tuner (not supplied)
(page 56).

Sony STR-DN1000 Specifications

General

Output power	200 W
Sound enhancement	Yes
Remote control type	RM-AAP042
Product color	Black
Audio output channels	7.1 channels
I/O ports	4x in, 1x out HDMI 1x coax. in
