In the video input/output conversion table classified by the menu
settings
a : Video signals are up-converted and output through the video converter.
f : The same type of signal as that of the input signal is output. Video signals are not converted.
X : Video signals are not output.
a)
The resolution is set automatically, depending on the connected TV.
b)
When the TV is connected to jacks other than the HDMI jacks, 480/576i signals are output when “Resolution”
is set to “AUTO”.
c)
480/576p signals are output even if 480/576i is set.
d)
Video signals without copyright protection are output based on the settings menu. Video signals with
copyright protection are output as 480p.
Notes
• Video signals are not output from the COMPONENT VIDEO MONITOR OUT or MONITOR VIDEO OUT
jacks when the TV, etc., is connected to the HDMI OUT jack.
• If you select a resolution that the connected TV does not support in the “Resolution” menu, the images from
the TV cannot be output correctly.
• Converted HDMI image output signals do not support “x.v.Color”.
• Converted HDMI image output signals do not support Deep Color.
• When HDMI OUT jack is connected, there is no up-converted video signal output from COMPONENT
VIDEO MONITOR OUT jacks. The COMPONENT VIDEO MONITOR OUT jacks have the component
signal direct output only.
• This receiver do not support 1080p input signals. You cannot up-convert the video signals to 1080p using this
receiver.
x Comp.Dec. (Component video decoder)
If the image is distorted when you connect to video game, set “Comp. Dec.” to “ON”. This setting
is only applicable for component video input signals.
•ON
•OFF
“Resolution”
menu setting
HDMI OUT
jack
COMPONENT
VIDEO
MONITOR OUT
jacks
MONITOR
VIDEO OUT
jack
DIRECT Component video X f X
Video XXf
AUTO (initial
setting)
Component video a
a)
a
b)
X
Video a
a)
a
b)
f
480/576i Component video a
c)
a X
Video a
c)
af
480/576p Component video aaX
Video aaf
720p, 1080i Component video aa
d)
X
Video aa
d)
f
Input signals
Output from
