– 37 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
KEY
KEY BOARD
**********
1-694-508-11 CONDUCTIVE BOARD, CONNECTION
* 3-030-824-01 PLATE, LIGHT GUIDE
* 3-030-825-01 HOLDER (LCD)
* 3-030-839-01 SHEET (REFLECTOR)
* 3-030-840-01 PLATE (B), GROUND
< CAPACITOR >
C952 1-163-033-00 CERAMIC CHIP 0.022uF 50V
C953 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C954 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C955 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C956 1-164-222-11 CERAMIC CHIP 0.22uF 25V
< CONNECTOR >
CNP901 1-785-775-11 PIN, CONNECTOR 15P
< DIODE >
D902 8-719-105-99 DIODE RD6.2M-B1
D903 8-719-105-99 DIODE RD6.2M-B1
D904 8-719-105-99 DIODE RD6.2M-B1
D951 8-719-422-49 DIODE MA8056-L
< IC >
IC901 8-759-366-34 IC LC75824E
< LIQUID CRYSTAL DISPLAY >
LCD901 1-803-495-11 DISPLAY PANEL, LIQUID CRYSTAL
< SWITCH >
LSW901 1-771-609-11 SWITCH, TACTILE (WITH LED) (OFF)
LSW902 1-762-619-21 SWITCH, KEY BOARD (WITH LED) (SOURCE)
LSW903 1-762-619-21 SWITCH, KEY BOARD (WITH LED)
(MODE *)
LSW905 1-762-619-21 SWITCH, KEY BOARD (WITH LED) (SOUND)
LSW906 1-762-619-21 SWITCH, KEY BOARD (WITH LED) (SHIFT)
LSW921 1-762-619-21 SWITCH, KEY BOARD (WITH LED) (6)
LSW922 1-762-619-21 SWITCH, KEY BOARD (WITH LED)
(– DISC, – PRESET)
LSW923 1-762-619-21 SWITCH, KEY BOARD (WITH LED)
(+ DISC, + PRESET)
LSW927 1-762-619-21 SWITCH, KEY BOARD (WITH LED) (DSPL)
LSW928 1-771-609-11 SWITCH, TACTILE (WITH LED) (6)
LSW929 1-771-609-11 SWITCH, TACTILE (WITH LED) (5)
LSW930 1-771-609-11 SWITCH, TACTILE (WITH LED) (4, →)
LSW931 1-771-609-11 SWITCH, TACTILE (WITH LED)
(3, PLAY MODE)
LSW932 1-771-609-11 SWITCH, TACTILE (WITH LED) (2, SET UP)
LSW933 1-771-609-11 SWITCH, TACTILE (WITH LED) (1, ←)
< PILOT LAMP >
PL901 1-517-633-21 LAMP, PILOT (LCD BACK LIGHT)
PL902 1-517-633-21 LAMP, PILOT (LCD BACK LIGHT)
< TRANSISTOR >
Q945 8-729-900-53 TRANSISTOR DTC114EK
< RESISTOR >
R901 1-216-647-11 METAL CHIP 680 0.5% 1/10W
R902 1-216-647-11 METAL CHIP 680 0.5% 1/10W
R903 1-216-647-11 METAL CHIP 680 0.5% 1/10W
R904 1-216-651-11 METAL CHIP 1K 0.5% 1/10W
R905 1-216-655-11 METAL CHIP 1.5K 0.5% 1/10W
R906 1-216-655-11 METAL CHIP 1.5K 0.5% 1/10W
R907 1-216-659-11 METAL CHIP 2.2K 0.5% 1/10W
R916 1-216-033-00 METAL CHIP 220 5% 1/10W
R921 1-216-647-11 METAL CHIP 680 0.5% 1/10W
R922 1-216-647-11 METAL CHIP 680 0.5% 1/10W
R923 1-216-647-11 METAL CHIP 680 0.5% 1/10W
R924 1-216-651-11 METAL CHIP 1K 0.5% 1/10W
R925 1-216-655-11 METAL CHIP 1.5K 0.5% 1/10W
R926 1-216-655-11 METAL CHIP 1.5K 0.5% 1/10W
R927 1-216-659-11 METAL CHIP 2.2K 0.5% 1/10W
R928 1-216-663-11 METAL CHIP 3.3K 0.5% 1/10W
R929 1-216-667-11 METAL CHIP 4.7K 0.5% 1/10W
R930 1-216-671-11 METAL CHIP 6.8K 0.5% 1/10W
R931 1-208-806-11 RES, CHIP 10K 2% 1/10W
R932 1-208-810-11 RES, CHIP 15K 2% 1/10W
R951 1-216-041-00 METAL CHIP 470 5% 1/10W
R953 1-216-121-00 RES, CHIP 1M 5% 1/10W
R954 1-216-049-11 RES, CHIP 1K 5% 1/10W
R955 1-216-049-11 RES, CHIP 1K 5% 1/10W
R956 1-216-049-11 RES, CHIP 1K 5% 1/10W
R957 1-216-109-00 METAL CHIP 330K 5% 1/10W
R961 1-216-021-00 METAL CHIP 68 5% 1/10W
R963 1-216-033-00 METAL CHIP 220 5% 1/10W
SECTION 8
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
When indicating parts by reference
number, please include the board.
