– 9 –
SUB P
ANEL,
MECHANISM DECK (MG-25F-136)
MAIN BO
ARD,
HEA
T SINK
Note:
Follow the disassemb
ly pr
ocedur
e in the numerical order giv
en.
SECTION 2
DISASSEMBL
Y
1
three screws
(PTT2.6
×
8)
2
sub panel
3
connector
(CN351)
5
screw
(PTT2.6
×
6)
6
mechanism dec
k
(MG-25F-136)
4
flexib
le flat cable
(CN301)
1
three screws
(PTT2.6
×
8)
3
two ground point
screws
5
three screws
(PTT2.6
×
8)
5
two screws
(PTT2.6
×
10)
1
screw
(PTT2.6
×
8)
5
two screws
(PTT2.6
×
8)
6
heat sink
2
rubber cap (25)
1
two screws
(PTT2.6
×
8)
4
main board
8
10
