5. Insert the board removed in step 3 into the rail of the EX-1132B extension board, and securely connect the
connectors of both boards.
Tip
When removing the inspected or adjusted board, open the right and left levers in the arrow directions.
Lever
Lever
Inspect or adjust
board
XVS-8000-C/XVS-8000
1-11
