1-1. Location of Main Parts
1-1-1. Front Board
8
2
3
6
8
7
4
5
1
No, Board name Function Remarks
1 CA-92 Unit control/reference generator/GbE hub board XVS-8000
2 DVP-53A HD DME board XKS-8470
3 MIX-57 Mix/Effect board XKS-8210
4 OUT-38 Output processor board XVS-8000
5 OUT-38A Output processor board XKS-8160
6 VPR-129 Frame memory board XKS-8440
7 VPR-129A Format converter board XKS-8460
8 XPT-38 XPT + Multi viewer board XVS-8000
