– 16 –
3-22. BATT L BOARD
3-21. KEY BOARD
1
Screws
+P 2.6
×
8
2
Panel DECO sub ASSY
Key board
3
Screws
+PTPWH 3
×
10
5
1
1
2
4
Cover, wire
BATT L board
Lid, Battery case
Cabinet rear ASSY
