Sony ZS-D55 Service Manual

– 68 –
NOTE :
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms
METAL : Metal-film resistor
METAL OXIDE :Metal oxide-film resistor
F : nonflammable
• Items marked “ * ”are not stocked since
they are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u : µ , for example :
uA.... : µ A.... , uPA.... : µ PA....
uPB.... : µ PB.... , uPC.... : µ PC....
uPD.... : µ PD....
• CAPACITORS
uF : µ F
• COILS
uH : µ H
• Abbreviation
IT : Italian EE : East European
JE : Tourist CIS : Russian
When indicating parts by reference num-
ber, please include the board.
The components identified by mark 0
or dotted line with mark 0 are critical
for safety.
Replace only with part number specified.
SECTION 8
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
* A-3322-979-A AUDIO BOARD, COMPLETE
**********************
7-685-645-79 SCREW +P 3X6 TYPE2 NON-SLIT
< CAPACITOR >
C113 1-127-880-21 CERAMIC 0.022uF 10% 50V
C114 1-126-960-11 ELECT 1uF 20% 50V
C115 1-126-960-11 ELECT 1uF 20% 50V
C116 1-126-960-11 ELECT 1uF 20% 50V
C117 1-126-960-11 ELECT 1uF 20% 50V
C118 1-126-963-11 ELECT 4.7uF 20% 50V
C119 1-126-964-11 ELECT 10uF 20% 50V
C120 1-130-475-00 MYLAR 0.0022uF 5% 50V
C121 1-136-495-11 MYLAR 0.068uF 5% 50V
C122 1-136-495-11 MYLAR 0.068uF 5% 50V
C123 1-136-169-00 MYLAR 0.22uF 5% 50V
C124 1-136-169-00 MYLAR 0.22uF 5% 50V
C125 1-104-665-11 ELECT 100uF 20% 10V
C126 1-126-963-11 ELECT 4.7uF 20% 50V
C127 1-126-963-11 ELECT 4.7uF 20% 50V
C128 1-162-282-31 CERAMIC 100PF 10% 50V
C130 1-104-664-11 ELECT 47uF 20% 10V
C131 1-104-664-11 ELECT 47uF 20% 10V
C132 1-130-485-00 MYLAR 0.015uF 5% 50V
C133 1-130-485-00 MYLAR 0.015uF 5% 50V
C135 1-104-665-11 ELECT 100uF 20% 10V
C136 1-104-665-11 ELECT 100uF 20% 10V
C140 1-162-303-11 CERAMIC 0.0033uF 30% 16V
C141 1-162-282-31 CERAMIC 100PF 10% 50V
C145 1-162-306-11 CERAMIC 0.01uF 30% 16V
C146 1-127-872-21 CERAMIC 4700PF 10% 50V
C147 1-162-294-31 CERAMIC 0.001uF 10% 50V
C148 1-162-282-31 CERAMIC 100PF 10% 50V
C149 1-162-282-31 CERAMIC 100PF 10% 50V
C150 1-162-282-31 CERAMIC 100PF 10% 50V
C151 1-162-282-31 CERAMIC 100PF 10% 50V
C152 1-162-282-31 CERAMIC 100PF 10% 50V
C153 1-162-282-31 CERAMIC 100PF 10% 50V
C156 1-126-963-11 ELECT 4.7uF 20% 50V
C213 1-127-880-21 CERAMIC 0.022uF 10% 50V
C214 1-126-960-11 ELECT 1uF 20% 50V
C215 1-126-960-11 ELECT 1uF 20% 50V
C216 1-126-960-11 ELECT 1uF 20% 50V
C217 1-126-960-11 ELECT 1uF 20% 50V
C218 1-126-963-11 ELECT 4.7uF 20% 50V
C219 1-126-964-11 ELECT 10uF 20% 50V
C220 1-130-475-00 MYLAR 0.0022uF 5% 50V
C221 1-136-495-11 MYLAR 0.068uF 5% 50V
C222 1-136-495-11 MYLAR 0.068uF 5% 50V
C223 1-136-169-00 MYLAR 0.22uF 5% 50V
C224 1-136-169-00 MYLAR 0.22uF 5% 50V
C225 1-104-665-11 ELECT 100uF 20% 10V
C226 1-126-963-11 ELECT 4.7uF 20% 50V
C227 1-126-963-11 ELECT 4.7uF 20% 50V
C228 1-162-282-31 CERAMIC 100PF 10% 50V
C230 1-104-664-11 ELECT 47uF 20% 10V
C231 1-104-664-11 ELECT 47uF 20% 10V
C232 1-130-485-00 MYLAR 0.015uF 5% 50V
C233 1-130-485-00 MYLAR 0.015uF 5% 50V
C235 1-104-665-11 ELECT 100uF 20% 10V
C236 1-104-665-11 ELECT 100uF 20% 10V
C240 1-162-303-11 CERAMIC 0.0033uF 30% 16V
C241 1-162-282-31 CERAMIC 100PF 10% 50V
C245 1-162-306-11 CERAMIC 0.01uF 30% 16V
C246 1-127-872-21 CERAMIC 4700PF 10% 50V
C247 1-162-294-31 CERAMIC 0.001uF 10% 50V
C248 1-162-282-31 CERAMIC 100PF 10% 50V
C249 1-162-282-31 CERAMIC 100PF 10% 50V
C250 1-162-282-31 CERAMIC 100PF 10% 50V
C251 1-162-282-31 CERAMIC 100PF 10% 50V
C252 1-162-282-31 CERAMIC 100PF 10% 50V
C253 1-162-282-31 CERAMIC 100PF 10% 50V
C256 1-126-963-11 ELECT 4.7uF 20% 50V
C300 1-128-548-11 ELECT 4700uF 20% 25V
C319 1-126-963-11 ELECT 4.7uF 20% 50V
C320 1-127-888-21 CERAMIC 0.1uF 10% 50V
C321 1-126-925-11 ELECT 470uF 20% 10V
C322 1-104-664-11 ELECT 47uF 20% 10V
C323 1-127-888-21 CERAMIC 0.1uF 10% 50V
C326 1-104-666-11 ELECT 220uF 20% 25V
C327 1-162-306-11 CERAMIC 0.01uF 30% 16V
C329 1-126-964-11 ELECT 10uF 20% 50V
C331 1-162-306-11 CERAMIC 0.01uF 30% 16V
C332 1-162-306-11 CERAMIC 0.01uF 30% 16V
C333 1-126-960-11 ELECT 1uF 20% 50V
AUDIO
