page 30
Release 00 - 03/2018
Engine RS100 - RSC100
Service manual
9.2. Replacing the carburettor
1 - Perform operations 1 - 2 - 3 - 4 - 5 - 6 - 7 - 13 - 14
- 15 - 16 indicated in section [
9.1] above.
9.3. Adjusting maximum speed
NOTE: This operation is carried out by adju-
sting the governor system [ 10.2a].
9.4. Adjusting the carburation
NOTE: The carburation is set in the factory
and does not normally need changing. In the
event of irregular functioning, clean the car-
burettor as indicated in section [ 9.1].
Tightening torques
1 Carburettor nuts/lter 6-8 Nm
9. CARBURATION ( valid for RS100 model)
