FS 130, FS 130 R
English
32
Attaching the unit to the harness
The type and style of the harness and
carabiner (spring hook) depend on the
market.
N Attach the carabiner (1) to the
carrying ring (2) on the drive tube.
N Loosen the screw (3).
Balancing the brushcutter
The unit is balanced differently,
depending on the cutting attachment
used.
Proceed as follows until the conditions
specified under "Floating positions"
have been met:
N Adjust the carrying ring.
N Tighten the screw moderately.
N Allow the unit to hang freely.
N Check the position obtained.
Floating positions
Mowing tools (A) such as mowing
heads, grass cutting blades and brush
knives
N should just touch the ground.
Circular saw blades (B)
N should "hover" about 8 in. (20 cm)
above the ground.
When the correct floating position has
been reached:
N Tighten down the screw on the
carrying ring firmly.
Balancing the
Trimmer/Brushcutter
