Stihl FS 510 C-M User Manual

FS 510 C-M, FS 560 C-M
English
44
N Start the engine and check the
adjustment.
N Shut down the engine and repeat
adjustment if necessary.
Maintenance Work
STIHL recommends that you have
servicing and repair work carried out
exclusively by an authorized STIHL
servicing dealer.
Fuel Pickup Body in Tank
N Check the pickup body in the fuel
tank every year and have it replaced
if necessary.
The pickup body should be positioned in
the area of the tank shown in the
illustration.
Spark arrestor in muffler and spacer
N If the engine is down on power,
have the spark arrestor in the
muffler checked.
N Check spacer (2) for damage.
N Have damaged spacer (2) replaced
immediately.
Antivibration elements
Four antivibration elements (arrows) are
installed between the powerhead and
the drive tube. Have the system checked
if there is a noticeable increase in
vibrations.
Both vibration gaps (arrows) are preset
to the same width at the factory. If the
size of the two vibration gaps varies
greatly and/or one of them closes up,
have your servicing dealer repair the
antivibration system.
Inspections and Maintenance
by Dealer
2709BA022 KN
2709BA024 KN
2
4900BA028 KN
