Stihl FSA 45 User Manual

0458-718-8221-A
23
English 13 Inserting and Removing the Activation Key
To adjust the position of the loop handle:
► Switch off the trimmer, @ 14.2.
► Remove the activation key, @ 13.2.
► Loosen the star knob (1).
► Adjust the loop handle (2) to the desired operating
position.
► Tighten the star knob securely.
12.3 Converting the Trimmer for Edging
WARNING
To reduce the risk of injury from loss of control, ensure that
the loop handle and drive tube are properly adjusted and the
trimmer head adjustment latch are locked and secured at all
times while working.
The trimmer can be converted for use in edging applications.
To convert the FSA 45:
► Switch off the trimmer, @ 14.2.
► Remove the activation key, @ 13.2.
► Depress and hold the drive tube release button(1).
► Turn the loop handle(2) 90° around the drive tube until it
locks.
► Release the drive tube release button.
► Press and hold the trimmer head adjustment latch(4).
► Tilt the drive tube(3) down until it locks.
► Release the trimmer head adjustment latch.
13.1 Inserting the Activation Key
WARNING
To reduce the risk of severe personal injury from unintended
activation, never store the activation key in the trimmer.
1
2
0000-GXX-1412-A0
13 Inserting and Removing the Activation
Key
3
4
2
1
0000-GXX-1480-A1

Stihl FSA 45 Specifications

General

Type	Brush cutter
Head type	Blade
Telescopic	Yes
Handle type	D-loop handle
Product color	Black, Metallic, Orange
Uncertainty K	2 m/s²
Sound power level	87 dB
Vibration emission	4.9 m/s²
Sound pressure level	77 dB
Cutting diameter (max)	250 mm
Power source	Battery

Weight and Dimensions

Length	1100 mm
Weight	2300 g
