69
DEFRNLITESPTNOSVFIDAPLSK EN
0478 216 9906 A - EN
Compilation and storage of technical
documentation:
Sven Zimmermann
STIHL Tirol GmbH
The year of manufacture and machine
number appear on the rating plate of the
machine.
Langkampfen,
2019-01-02 (YYYY-MM-DD)
STIHL Tirol GmbH
p.p.
Head of Design
18.1 REACH
REACH is an EC Directive for the
registration, evaluation, authorisation and
restriction of chemicals.
Information on compliance with the
REACH Directive (EC) No. 1907/2006 is
available from www.stihl.com/reach.
Measured sound power level:
GH 460.0 101,4 dB(A)
GH 460.0 C 103,4 dB(A)
Guaranteed sound power level:
GH 460.0 104 dB(A)
GH 460.0 C 108 dB(A)
18. Technical specifications
GH 460.0 / GH 460.0 C:
Serial number 6012
Starter Rope start
Cutting unit MultiCut 450
Cutting unit drive Permanent
Wheel diameter 260 mm
GH 460.0:
Engine, design 4-stroke com-
bustion engine
Type
B&S Series 850
EXi OHV
Nominal output at
nominal speed
3,4 - 3000
kW - rpm
Displacement 190 ccm
Fuel tank 1,0 l
Maximum branch
diameter 60 mm
Nominal engine
speed 3000 rpm
In accordance with
Directive
2000/14/EC:
Guaranteed sound
power level L
WAd
104 dB(A)
In accordance with
Directive
2006/42/EC:
Sound pressure level
at workplace L
pA
96 dB(A)
Uncertainty K
pA
3dB(A)
L/W/H 108/85/137 cm
Weight 59 kg
GH 460.0 C:
Engine, design 4-stroke com-
bustion engine
Type B&S Power built
OHV (Series
3115)
Nominal output at
nominal speed
5,8 - 2800
kW - rpm
Displacement 344 ccm
GH 460.0 / GH 460.0 C:
Fuel tank 2,3 l
Maximum branch
diameter 75 mm
Nominal engine
speed 2800 rpm
In accordance with
Directive
2000/14/EC:
Guaranteed sound
power level L
WAd
108 dB(A)
In accordance with
Directive
2006/42/EC:
Sound pressure level
at workplace L
pA
97 dB(A)
Uncertainty K
pA
3 dB(A)
L/W/H 108/89/137 cm
Weight 75 kg
19. Troubleshooting
@ See engine instruction manual.
If necessary, contact a specialist
dealer; STIHL recommends STIHL
specialist dealers.
GH 460.0 C:
