HT 105, HT 134, HT 135
English
36
EPA / CEPA
The Emission Compliance Period
referred to on the Emissions
Compliance Label indicates the number
of operating hours for which the engine
has been shown to meet Federal
emission requirements.
Category
Engine
STIHL single cylinder four-stroke engine
with mixture lubrication
HT 105
HT 135
Ignition system
Electronic magneto ignition
This spark ignition system meets all
requirements of the Canadian
Interference-Causing Equipment
Standard CAN ICES-2/NMB-2.
Fuel system
All-position diaphragm carburetor with
integral fuel pump
Chain lubrication
Fully automatic, speed-controlled oil
pump with rotary piston
Weight
Cutting attachment HT 105
The actual cutting length may be less
than the specified cutting length.
Rollomatic E Mini / Rollo Light 01 guide
bar
Saw chain 1/4" P
Chain sprocket
Cutting attachment HT 135
The actual cutting length may be less
than the specified cutting length.
Rollomatic E Mini / Rollo Light 01 guide
bar
Specifications
A = 300 hours
B = 125 hours
C = 50 hours
Displacement: 31.4cm
3
Cylinder bore: 40 mm
Piston stroke: 25 mm
Engine power to
ISO 8893:
1.05 kW (1.4 hp)
at 7500 1/min
Idle speed to ISO
11680: 2800 ± 50 rpm
Cut-off speed (nomi-
nal value): 9500 rpm
Valve clearance
Inlet valve: 0.10 mm
Exhaust valve: 0.10 mm
Displacement: 36.3cm
3
Cylinder bore: 43 mm
Piston stroke: 25 mm
Engine power to
ISO 8893:
1.4 kW (1.9 hp) at
8500 1/min
Idle speed to ISO
11680: 2800 ± 50 rpm
Cut-off speed (nomi-
nal value): 9500 rpm
Valve clearance
Inlet valve: 0.10 mm
Exhaust valve: 0.10 mm
Spark plug
(suppressed):
HT 105: Bosch USR 7 AC
HT 135: NGK CMR 6 H
Electrode gap: 0.5 mm
Fuel tank capacity: 530 cm
3
(0.53 l)
Oil tank capacity: 220 cm
3
(0.22 l)
dry, without cutting attachment
HT 105: 7.9 kg
HT 135: 7.9 kg
Blade length: 25, 30, 35 cm
Pitch: 1/4" P (6.35 mm)
Groove width: 1.1 mm
Picco Micro3 (71PM3) Type 3670
Pitch: 1/4" P (6.35 mm)
Drive link gauge: 1.1 mm
8-tooth for 1/4" P
Blade length: 25, 30, 35 cm
Pitch: 3/8" P (9.32 mm)
Groove width: 1.1 mm
