Stihl RMA 443 VC User Manual

0478-131-9948-A
52
English 10 Inserting and Removing the Activation Key
► Open flap (1) as far as the stop and hold.
► Press locking lever (2).
The battery (3) is released.
► Remove battery (3).
► Close flap (1).
10.1 Inserting the Activation Key
► Open flap (1) as far as the stop and hold.
► Insert activation key (2) in key receptacle (3).
► Close flap (1).
10.2 Removing the Activation Key
► Open the flap as far as the stop and hold.
► Pull out the activation key.
► Close the flap.
► Keep the activation key out of the reach of children.
11.1 Activating and Deactivating the Blade
11.1.1 Activating the Blade
► Place the lawn mower on a level surface.
► Press locking button (1) with the right hand and hold.
► Pull control bar for mowing (2) with the left hand fully in the
direction of handlebar (3) and hold so the thumb encloses
handlebar (3).
The blade turns.
► Release locking button (1).
► Hold handlebar (3) and control bar for mowing (2) with the
right hand so the thumb encloses handlebar (3).
11.1.2 Deactivating the Blade
► Release the control bar for mowing.
► Wait until the blade is no longer turning.
10 Inserting and Removing the Activation
Key
11 Switching the Lawn Mower On and Off

Stihl RMA 443 VC Specifications

General

Type	Walk behind lawn mower
Cutting width	410 mm
Grass catcher	Yes
Product color	Black, Grey, Orange
Uncertainty K	0.9 m/s²
Number of wheels	4 wheel(s)
Rotational speed	3150 RPM
Maximum lawn area	420 m²
Mulching function	-
Sound power level	90 dB
Handle(s) features	Foldable
Vibration emission	1.8 m/s²
Rear wheels diameter	200 mm
Sound pressure level	89.2 dB
Front wheels diameter	180 mm
Maximum cutting height	75 mm
Minimum cutting height	25 mm
Grass collecting volume	55 L
Suitable for slope up to	14 °
Power source	Battery
Battery voltage	36 V

Weight and Dimensions

Depth	1380 mm
Width	490 mm
Height	1080 mm
Weight	23000 g
