Stihl RMA 443 VC User Manual

0478-131-9948-A
55
English 13 Operating the Lawn Mower
13.1 Holding and Guiding the Lawn Mower
► Hold the handlebar with both hands so the thumbs
enclose the handlebar.
13.2 Adjusting the Cutting Height
Six cutting heights can be set:
– 25 mm = position 1
– 30 mm = position 2
–40mm = position3
–50mm = position4
–60mm = position5
– 75 mm = position 6
The positions are indicated on the lawn mower.
► Hold the lawn mower at handle (1).
► Press and hold lever (2).
► Move the lawn mower to the desired position by raising
and lowering the lever.
The current cutting height can be read off at cutting height
indicator (3) by means of marking (4).
► Release lever (2).
The lawn mower engages.
13.3 Activating ECO Mode
When ECO mode is activated, the lawn mower detects the
current working conditions and adjusts the blade speed
automatically.
This may extend the battery life.
► Open flap (1) as far as the stop and hold.
► Set ECO switch (2) to the I position.
13 Operating the Lawn Mower

Stihl RMA 443 VC Specifications

General

Type	Walk behind lawn mower
Cutting width	410 mm
Grass catcher	Yes
Product color	Black, Grey, Orange
Uncertainty K	0.9 m/s²
Number of wheels	4 wheel(s)
Rotational speed	3150 RPM
Maximum lawn area	420 m²
Mulching function	-
Sound power level	90 dB
Handle(s) features	Foldable
Vibration emission	1.8 m/s²
Rear wheels diameter	200 mm
Sound pressure level	89.2 dB
Front wheels diameter	180 mm
Maximum cutting height	75 mm
Minimum cutting height	25 mm
Grass collecting volume	55 L
Suitable for slope up to	14 °
Power source	Battery
Battery voltage	36 V

Weight and Dimensions

Depth	1380 mm
Width	490 mm
Height	1080 mm
Weight	23000 g
