Stihl RMA 443 VC User Manual

0478-131-9948-A
64
English 21 Specifications
21.1 STIHL RMA 443.2 VC, RMA 443.2 PV,
RMA 448.2 VC, RMA 448.2 PV Lawn Mower
– Permissible battery: STIHL AP
– Weight without battery:
– RMA 443.2 VC: 23.4 kg
– RMA 443.2 PV: 23.6 kg
– RMA 448.2 VC: 24.4 kg
– RMA 448.2 PV: 24.6 kg
– Maximum grass catcher box capacity: 55 l
– Cutting width:
– RMA 443.2 VC, RMA 443.2 PV: 41 cm
– RMA 448.2 VC, RMA 448.2 PV: 46 cm
– Speed: 3,150 rpm
– Speed in ECO mode: 2,800 rpm
– Minimum driving speed: 2.0 km/h
– Maximum driving speed (depending on the battery used):
– with AP 100: 3.0 km/h
– with AP 200: 3.7 km/h
– with AP 300: 4.5 km/h
For information on the battery life see
www.stihl.com/battery-life.
21.2 Blade
– Minimum thickness a: 2 mm
– Minimum width b: 55 mm
– Sharpening angle c: 30°
21.3 STIHL AP battery
– Battery Technology: Lithium-ion
– Voltage: 36 V
– Capacity in Ah: see rating label
– Energy content in Wh: see rating label
– Weight in kg: see rating label
– Permissible temperature range for operation and storage:
-10°C to +50°C
21.4 Sound Values and Vibration Values
RMA 443.2 VC, RMA 443.2 PV
The K value for the sound pressure level is 2 dB(A). The K
value for the sound power level is 1.2 dB(A). The K value for
the vibration values is 1.10 m/s².
21 Specifications

Stihl RMA 443 VC Specifications

General

Type	Walk behind lawn mower
Cutting width	410 mm
Grass catcher	Yes
Product color	Black, Grey, Orange
Uncertainty K	0.9 m/s²
Number of wheels	4 wheel(s)
Rotational speed	3150 RPM
Maximum lawn area	420 m²
Mulching function	-
Sound power level	90 dB
Handle(s) features	Foldable
Vibration emission	1.8 m/s²
Rear wheels diameter	200 mm
Sound pressure level	89.2 dB
Front wheels diameter	180 mm
Maximum cutting height	75 mm
Minimum cutting height	25 mm
Grass collecting volume	55 L
Suitable for slope up to	14 °
Power source	Battery
Battery voltage	36 V

Weight and Dimensions

Depth	1380 mm
Width	490 mm
Height	1080 mm
Weight	23000 g
