Stihl RMA 443 VC User Manual

0478-131-9948-A
58
English 16 Storing
► Secure the packaging so that it cannot move.
The battery is subject to the requirements for the transport
of dangerous goods. The battery is classified as UN 3480
(lithium-ion batteries) and has been tested in accordance
with UN Manual of Tests and Criteria, Part III, sub-section
38.3.
For transport regulations see www.stihl.com/safety-data-
sheets
16.1 Storing the Lawn Mower
► Switch the lawn mower off, pull out the activation key and
remove the battery.
► Store the lawn mower in accordance with the following
conditions:
– The lawn mower is out of the reach of children.
– The lawn mower is clean and dry.
– The lawn mower cannot tip over.
16.2 Storing the Battery
STIHL recommends that you store the battery with a charge
between 40% and 60% (2 LEDs glow green).
► Check the following points when storing the battery:
– Battery is out of the reach of children.
– Battery is clean and dry.
– Battery is in an enclosed location.
– Battery is stored separately from the mower and
charger.
– Battery is in non-conductive packaging.
– Battery is in a temperature range between -10°C and
+50°C.
17.1 Placing the Lawn Mower in the Cleaning
Position
► Switch the lawn mower off, pull out the activation key and
remove the battery.
► Place the lawn mower on a level surface.
► Detach the grass catcher box.
► Set the cutting height to the highest setting. @ 13.2
► Move the upper handlebar to the lowest position, @ 8.1.
► Press lever (1) downwards with the left hand and hold.
► Hold the lawn mower at transport handle (2) with the right
hand and upend.
17.2 Cleaning the Lawn Mower
► Switch the lawn mower off, pull out the activation key and
remove the battery.
► Clean the lawn mower with a damp cloth.
► Clean the discharge chute with a soft brush or a damp
cloth.
► Remove any foreign bodies from the battery compartment
and clean the battery compartment with a damp cloth.
► Clean the electric contacts in the battery compartment
with a paintbrush or a soft brush.
► Clean the ventilation slots with a paintbrush.
16 Storing
17 Cleaning

Stihl RMA 443 VC Specifications

General

Type	Walk behind lawn mower
Cutting width	410 mm
Grass catcher	Yes
Product color	Black, Grey, Orange
Uncertainty K	0.9 m/s²
Number of wheels	4 wheel(s)
Rotational speed	3150 RPM
Maximum lawn area	420 m²
Mulching function	-
Sound power level	90 dB
Handle(s) features	Foldable
Vibration emission	1.8 m/s²
Rear wheels diameter	200 mm
Sound pressure level	89.2 dB
Front wheels diameter	180 mm
Maximum cutting height	75 mm
Minimum cutting height	25 mm
Grass collecting volume	55 L
Suitable for slope up to	14 °
Power source	Battery
Battery voltage	36 V

Weight and Dimensions

Depth	1380 mm
Width	490 mm
Height	1080 mm
Weight	23000 g
