Illustrated index
Exterior
12
3
5
6
4
13
1
1
12
8
9
10
7
000139
1)
Engine hood lock release (pa
ge 11-4)
2)
Headlight switch (page 3-31)
3)
Bulb replacement (page
11-49)
4)
Wiper switch (page 3-35)
5)
Moonroof (page 2-25)
6)
Roof ra
il (page 8-14
)
7)
Door locks (page 2-4)
8)
Tire pressure (page 11-35)
9)
Flat tires (page 9-4)
10)
Tire chai
ns (page 8-11)
11)
Fog
light switch (page 3-34
)
12)
Tie-down hoo
ks (page 9-13)
13)
Towi
ng hook (page 9-13)
12
14
