12-10
Specifications
Vehicle identification
C00104
1
2
7
6
5
4
3
1)
Emission control label
2)
Vehicle identification number
3)
Certification and
bar code label
4)
Tire inflation pressure label
5)
Vehicle identification number plate
6)
Model number plate
7)
Fuel label
