16
Light control and wiper c
ontrol levers/switches
1
6
7
11
10
9
8
2
3
4
5
000074
1)
Parking light switch (page 3-33)
2)
Windshield wiper (pag
e 3-34)
3)
Mist (page 3-36)
4)
Windshield washer (pag
e 3-35)
5)
Rear window wiper and washer
switch (page 3-37)
6)
Wiper control le
ver (page 3-35)
7)
Light control lever (page 3-31)
8)
Fog light switch
(page 3-34)
9)
Headlight ON/OFF (page 3-31)
10)
Headl
ight flasher High/Low beam
change (page 3-31
)
11)
Turn sign
al (page 3-32)
