SPARE PARTS

Item Part Name Q’ty

1 Piston pin bearing 1

2 Sprocket spacer O-ring 2

3 Piston pin circlip 2

4 Cylinder head O-ring No.1 2

5 Cylinder head O-ring No.2 2

6 Cylinder cover gasket No.1 2

7 Cylinder cover gasket No.2 1

8 Cylinder cover gasket No.3 1

9 Cylinder gasket 2

0 Crankcase gasket 1

A Clutch cover gasket 1

B Magneto cover gasket 1

C Clutch cover outer O-ring 1

D Piston complete 1

E Piston pin 1

F Piston ring 4

G Exhaust pipe O-ring 2

H Brake lever 1

I Clutch lever 1
