5-15
OTHER CONTROLS AND EQUIPMENT
52RM0-01E
Center outlet
75RM019
When open, air comes out regardless of
the air flow selector position.
Side outlet
52RM50230
Move the knob (1) vertically or horizontally,
to adjust the direction of airflow as desired.
The side outlet opens when you turn the
dial (2) upward and closes when you turn it
downward.
Heating system
Description of controls
52RM50240
Temperature selector (1)
This is used to adjust the temperature.
Blower speed selector (2)
This is used to turn on the blower and to
select blower speed.
CAUTION
Prolonged exposure to hot air from
the heater or air conditioner could
result in low temperature burns. All
vehicle occupants, particularly chil-
dren, the elderly, those with special
needs, individuals with delicate skin,
and sleeping individuals, should
maintain sufficient distance from the
air outlets to prevent prolonged
exposure to hot airflow.
(1)
(2)
