7-49
INSPECTION AND MAINTENANCE
52RM0-01E
52RM70470
3) Slide the blade out as shown.
NOTE:
Do not flex the wiper blade frame end more
than necessary. If you do, it can break off.
52RM70480
(1) Retainer
4) If the new blade is provided without the
two metal retainers, move them from
the old blade to the new one.
5) Install the new blade in the reverse
order of removal.
Check that the blade is properly
retained by all the hooks.
6) Reinstall wiper frame to arm in the
reverse order of removal.
Windshield washer fluid
80JM078
